– 30 –
KV-BM142M70
RM-W101
4. Rasie/lower data using the 3 and 6 buttons adjust
the following items:-
GEOM : 000 HPOS Horizontal Shift (HS)
001 HPAR Horizontal Parallelogram
002 HBOW Horizontal Bow
003 VLIN Vertical Linearity
004 VSCR Vertical Scroll
005 HSIZ EW Width (EW)
006 EWPW EW Parabola/Width (PW)
007 UCOP EW Upper Corner Parabola
008 LCOP EW Lower Corner Parabola
009 EWTZ EW Trapezium
010 VSLP Vertical Slope (VS)
011 VSIZ Vertical Amplitude
012 SCOR S-Correction (SC)
013 VPOS Vertical Shift (VSH)
014 HBL RGB Blanking Mode
015 WBF Timing of Wide Blanking (WBF)
016 WBR Timing of Wide Blanking (WBR)
017 SBL Service Blanking
018 COPY Copy the GEOM data to all
50/60Hz NVM area
5. Write into memory by pressing [MUTING] then - on
the remote commander.
WIDE MODE (50Hz)
(V-Compression Adjustment)
1. Input SPCB signal.
2. Adjust condition change to WIDE MODE : ON
3. Copy (Item from normal mode 50Hz) all Normal
Mode adjusted data.
NORMAL MODE (60Hz)
1. Input 525/60Hz signal.
2. They can copy 50Hz first.
("COPY" under GEOM is set to
1, then [MUTE] + -)
3. Using the
1 and 4 button, select category GEOM
(Service Mode).
4. Raise/lower data using the
3 and 6 buttons to
obtain optimum image.
GEOM : 000 HPOS Horizontal Shift (HS)
001 HPAR Horizontal Parallelogram
002 HBOW Horizontal Bow
003 VLIN Vertical Linearity
004 VSCR Vertical Scroll
005 HSIZ EW Width (EW)
006 EWPW EW Parabola/Width (PW)
007 UCOP EW Upper Corner Parabola
008 LCOP EW Lower Corner Parabola
009 EWTZ EW Trapezium
010 VSLP Vertical Slope (VS)
011 VSIZ Vertical Amplitude
012 SCOR S-Correction (SC)
013 VPOS Vertical Shift (VSH)
014 HBL RGB Blanking Mode
015 WBF Timing of Wide Blanking (WBF)
016 WBR Timing of Wide Blanking (WBR)
017 SBL Service Blanking
018 COPY Copy the GEOM data to all
50/60Hz NVM area
WIDE MODE (60Hz)
(V-Compression Adjustment)
1. Input mono scope signal.
2. Adjust condition change to WIDE MODE : ON
3. "COPY" is set to
1, then [MUTE] + -
