– 57 –
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
KV-BM142M70
RM-W101
* A-1075-948-A COMPLETE PWB, A
******************
4-382-854-01 SCREW (M3X8),P, SW (+)
4-382-854-21 SCREW (M3X14),P, SW (+)
*A012 4-102-022-01 PIN(30), WIRE
*A015 4-055-304-01 HOLDER, LED
*A016 4-042-408-02 PIN(45), WIRE
*A018 4-042-408-02 PIN(45), WIRE
<CAPACITOR>
C001 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C002 1-126-935-11 ELECT 470UF 20.00% 16V
C003 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C004 1-126-933-11 ELECT 100UF 20.00% 16V
C005 1-126-933-11 ELECT 100UF 20.00% 16V
C006 1-126-925-91 ELECT 470UF 20.00% 10V
C008 1-126-947-11 ELECT 47UF 20.00% 35V
C010 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C012 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C013 1-126-933-11 ELECT 100UF 20.00% 16V
C014 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C018 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C020 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C021 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C022 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C023 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C024 1-126-965-91 ELECT 22UF 20.00% 50V
C025 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C026 1-126-947-11 ELECT 47UF 20.00% 35V
C028 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C029 1-126-925-91 ELECT 470UF 20.00% 10V
C030 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C036 1-126-933-11 ELECT 100UF 20.00% 16V
C037 1-126-963-11 ELECT 4.7UF 20.00% 50V
C038 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C041 1-162-966-11 CERAMIC CHIP 0.0022UF 10.00% 50V
C042 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C044 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C046 1-162-969-11 CERAMIC CHIP 0.0068UF 10.00% 25V
C048 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C049 1-164-227-11 CERAMIC CHIP 0.022UF 10.00% 25V
C050 1-126-964-11 ELECT 10UF 20.00% 50V
C052 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C053 1-164-227-11 CERAMIC CHIP 0.022UF 10.00% 25V
C054 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C055 1-100-829-11 FILM 0.15UF 5% 250V
C056 1-126-933-11 ELECT 100UF 20.00% 16V
C057 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C058 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C061 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V
C063 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C064 1-126-961-11 ELECT 2.2UF 20.00% 50V
C065 1-126-962-11 ELECT 3.3UF 20.00% 50V
C069 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C070 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C072 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C073 1-126-961-11 ELECT 2.2UF 20.00% 50V
C078 1-162-923-11 CERAMIC CHIP 47PF 5.00% 50V
C080 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C081 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C082 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C083 1-162-979-11 CERAMIC CHIP 0.0027UF 10.00% 50V
C089 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C090 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C091 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C092 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C093 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C094 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C095 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C096 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C100 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C101 1-126-964-11 ELECT 10UF 20.00% 50V
C102 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C104 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C106 1-126-963-11 ELECT 4.7UF 20.00% 50V
C107 1-126-935-11 ELECT 470UF 20.00% 16V
C108 1-126-935-11 ELECT 470UF 20.00% 16V
C109 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V
C111 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C115 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V
C116 1-162-968-11 CERAMIC CHIP 0.0047UF 10.00% 50V
C117 1-162-924-11 CERAMIC CHIP 56PF 5.00% 50V
C118 1-126-965-91 ELECT 22UF 20.00% 50V
C119 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C120 1-126-935-11 ELECT 470UF 20.00% 16V
C133 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C135 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C137 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C138 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C140 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C200 1-117-863-11 CERAMIC CHIP 0.47UF 10.00% 6.3V
C203 1-164-677-11 CERAMIC CHIP 0.033UF 10.00% 16V
C204 1-136-167-00 FILM 0.15UF 5.00% 50V
C206 1-164-227-11 CERAMIC CHIP 0.022UF 10.00% 25V
C209 1-126-959-11 ELECT 0.47UF 20.00% 50V
C210 1-126-968-11 ELECT 100UF 20.00% 50V
C211 1-126-963-11 ELECT 4.7UF 20.00% 50V
C212 1-126-942-61 ELECT 1000UF 20.00% 25V
C213 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C217 1-126-942-61 ELECT 1000UF 20.00% 25V
C218 1-126-965-91 ELECT 22UF 20.00% 50V
C219 1-126-934-11 ELECT 220UF 20.00% 16V
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
When indicating parts by reference
number, please include the board name.
• Items marked " ∗ " are not stocked since
they are seldom required for routine
service. Some delay should be antici-
pated when ordering these items.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
• All resistors are in ohms
• F : nonflammable
CAPACITORS
• MF : µF, PF : µµF
COILS
• MMH : mH, UH : µH
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
A
