– 59 –
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
KV-BM142M70
RM-W101
C912 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C917 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C918 1-164-346-11 CERAMIC CHIP 1UF 16V
C953 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C955 1-126-947-11 ELECT 47UF 20.00% 35V
C956 1-126-933-11 ELECT 100UF 20.00% 16V
C967 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C975 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C979 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C1019 1-125-891-11 CERAMIC CHIP 0.47UF 10.00% 10V
C1233 1-126-961-11 ELECT 2.2UF 20.00% 50V
C2602 1-102-114-00 CERAMIC 470PF 10.00% 50V
C2631 1-102-228-00 CERAMIC 470PF 10.00% 500V
C2636 1-126-972-11 ELECT 1000UF 20.00% 50V
C2648 1-126-952-11 ELECT 1000UF 20.00% 35V
<CONNECTOR>
* CN005 1-564-506-11 PLUG, CONNECTOR 3P
* CN202 1-564-506-11 PLUG, CONNECTOR 3P
* CN600 1-508-786-00 PIN, CONNECTOR (5MM PITCH) 2P
* CN601 1-691-134-11 PIN, CONNECTOR (PC BOARD) 2P
* CN602 ! 1-580-843-11 PIN, CONNECTOR (POWER)
* CN904 1-508-743-00 PIN, CONNECTOR 5P
CT131 1-767-774-22 TRAP, CERAMIC
CT139 1-767-775-22 TRAP, CERAMIC
<DIODE>
D002 8-719-081-97 DIODE MMDL914T1
D003 8-719-081-97 DIODE MMDL914T1
D023 8-719-069-60 DIODE UDZSTE-179.1B
D024 8-719-069-60 DIODE UDZSTE-179.1B
D025 8-719-069-60 DIODE UDZSTE-179.1B
D054 8-719-069-55 DIODE UDZSTE-175.6B
D055 8-719-069-55 DIODE UDZSTE-175.6B
D056 8-719-081-97 DIODE MMDL914T1
D057 8-719-081-97 DIODE MMDL914T1
D058 8-719-081-97 DIODE MMDL914T1
D059 8-719-081-97 DIODE MMDL914T1
D060 8-719-069-55 DIODE UDZSTE-175.6B
D061 8-719-081-97 DIODE MMDL914T1
D062 8-719-069-55 DIODE UDZSTE-175.6B
D063 8-719-081-97 DIODE MMDL914T1
D064 8-719-069-55 DIODE UDZSTE-175.6B
D065 8-719-069-55 DIODE UDZSTE-175.6B
D066 8-719-908-03 DIODE GP08D
D068 8-719-069-55 DIODE UDZSTE-175.6B
D071 8-719-081-97 DIODE MMDL914T1
D072 8-719-081-97 DIODE MMDL914T1
D074 8-719-081-97 DIODE MMDL914T1
D075 8-719-069-60 DIODE UDZSTE-179.1B
D076 8-719-081-97 DIODE MMDL914T1
D100 8-719-421-40 DIODE MA77
D103 8-759-157-40 IC UPC574J
D108 8-719-069-55 DIODE UDZSTE-175.6B
D109 8-719-069-55 DIODE UDZSTE-175.6B
D110 8-719-081-97 DIODE MMDL914T1
D111 8-719-081-97 DIODE MMDL914T1
D200 8-719-062-51 DIODE 1PS226-115
D201 8-719-081-97 DIODE MMDL914T1
D202 8-719-081-97 DIODE MMDL914T1
D203 8-719-081-97 DIODE MMDL914T1
D204 8-719-081-97 DIODE MMDL914T1
D205 8-719-081-97 DIODE MMDL914T1
D208 8-719-081-97 DIODE MMDL914T1
D211 8-719-062-51 DIODE 1PS226-115
D212 8-719-081-97 DIODE MMDL914T1
D213 8-719-081-97 DIODE MMDL914T1
D214 8-719-081-97 DIODE MMDL914T1
D600 8-719-081-97 DIODE MMDL914T1
D602 6-500-481-31 DIODE AM01AV1
D603 6-500-481-31 DIODE AM01AV1
D604 8-719-077-77 DIODE D3SB60F3
D605 8-719-109-85 DIODE RD5.1ESB2
D608 8-719-109-85 DIODE RD5.1ESB2
D614 8-719-923-86 DIODE MTZJ-T-77-15
D615 8-719-063-70 DIODE D1NL20U
D617 6-500-567-11 DIODE 10ERB20-TA2B5
D618 8-719-063-70 DIODE D1NL20U
D619 6-500-567-11 DIODE 10ERB20-TA2B5
D621 8-719-312-10 DIODE RU4AM-T3
D622 8-719-085-37 DIODE 11EQS10-TB5
D623 6-500-567-31 DIODE 10ERB20-TB3
D624 8-719-510-73 DIODE S3L20UF4
D629 8-719-109-85 DIODE RD5.1ESB2
D633 8-719-923-86 DIODE MTZJ-T-77-15
D635 8-719-083-57 DIODE UDZSTE-173.6B
D637 8-719-072-70 DIODE MA2ZD14001S0
D638 8-719-081-97 DIODE MMDL914T1
D639 8-719-027-22 DIODE D3S6M-F
D804 8-719-991-33 DIODE 1SS133T-77
D805 8-719-991-33 DIODE 1SS133T-77
D807 8-719-991-33 DIODE 1SS133T-77
D808 8-719-991-33 DIODE 1SS133T-77
D809 8-719-991-33 DIODE 1SS133T-77
D815 8-719-069-60 DIODE UDZSTE-179.1B
D816 8-719-081-00 DIODE BY228/A52A/
D817 8-719-971-66 DIODE RGP15J-6040G23
D818 8-719-109-85 DIODE RD5.1ESB2
D819 6-500-567-31 DIODE 10ERB20-TB3
D820 8-719-908-03 DIODE GP08D
D821 6-500-567-31 DIODE 10ERB20-TB3
D823 8-719-302-43 DIODE EL1Z
D824 8-719-302-43 DIODE EL1Z
D827 8-719-302-43 DIODE EL1Z
D829 8-719-069-55 DIODE UDZSTE-175.6B
D830 8-719-081-97 DIODE MMDL914T1
D900 8-719-069-60 DIODE UDZSTE-179.1B
D901 8-719-069-60 DIODE UDZSTE-179.1B
D907 8-719-069-55 DIODE UDZSTE-175.6B
D908 8-719-069-55 DIODE UDZSTE-175.6B
D914 8-719-083-18 DIODE SPB-25MVWF
D915 8-719-069-55 DIODE UDZSTE-175.6B
D918 8-719-069-55 DIODE UDZSTE-175.6B
D931 8-719-083-57 DIODE UDZSTE-173.6B
D932 8-719-083-57 DIODE UDZSTE-173.6B
D2625 8-719-510-73 DIODE S3L20UF4
<DY CONNECTOR>
* DY800 1-580-798-11 CONNECTOR PIN (DY) 6P
A
