46
Specifications
negative
Horizontal sync input: 1-5 Vp-p
high impedance, positive/
negative
VD:
Vertical sync input: 1-5 Vp-p
high impedance, positive/
negative
AUDIO: Stereo minijack
(Common INPUT A/B), rated
input 500 mVrms, input
impedance 47 kilohms
INPUT B Analog RGB: HD D-sub 15-pin
(female)
R: 0.7 Vp-p ±2 dB (75 ohms
terminated)
G: 0.7 Vp-p ±2 dB (75 ohms
terminated)
G with sync: 1 Vp-p ±2 dB sync
negative (75 ohms terminated)
B: 0.7 Vp-p ±2 dB (75 ohms
terminated)
SYNC HD: Composite sync
input: 1 - 5 Vp-p high
impedance, positive/negative
Horizontal sync input: 1 - 5
Vp-p high impedance, positive/
negative
VD: Vertical sync input: 1 - 5
Vp-p high impedance, positive/
negative
USB Up (female) × 1
Wireless LAN card slot (VPL-CX86 only)
× 1
“Memory Stick” slot (VPL-CX86 only)
× 1
OUTPUT MONITOR OUT: HD D-sub 15-
pin (female)
R, G, B: Gain Unity: 75 ohms
SYNC/HD, VD: 4 Vp-p (open),
1 Vp-p (75 ohms)
AUDIO OUT (variable out):
Stereo minijack
1 Vrms (When the volume is
maximum and an input signal is
500 mVrms), output impedance
5 kilohms
REMOTE RS-232C: D-sub 9 pin
Safety regulations
UL60950, cUL (CSA No. 60950),
FCC Class B, IC Class B,
DEMKO (EN60950), CE
(LVD, EMC), C-Tick
Laser (VPL-CX86 only)
Laser type Class 2
Wavelength 640 nm - 660 nm
Output 1 mW
General
Dimensions 328 × 92.6 × 283.8 mm (13 × 3
3
/
4
× 11
1
/
4
inches) (w/h/d)
(without the projection parts)
Mass Approx. 3.8 kg (8 lb 6 oz)
Power requirements
AC 100 to 240 V, 2.8 to 1.2 A,
50/60 Hz
Power consumption
Max. 280 W
(in standby (standard): 7 W
(VPL-CX86), 5W (VPL-CX80)
in standby (low): 0.5 W)
Heat dissipation
921.3 BTU
Operating temperature
0°C to 35°C (32°F to 95°F)
Operating humidity
35% to 85% (no condensation)
Storage temperature
–20°C to +60°C (–4°F to +140°F)
Storage humidity
10% to 90%
Supplied accessories
Remote Commander (1)
Size AA (R6) batteries (2)
HD D-sub 15 pin cable (2 m) (1)
(1-791-992-xx)
USB cable A type - B type (1)
(1-790-081-xx)
Carrying case (1)
AC power cord (1)
Air filter (for replacement) (1)
CD-ROM (Application software
and Operating instructions) (1)
Quick Reference Manual (1)
Safety Regulations (1)
Security Label (1)
VPL-CX86 only
Presentation tool (1)
Size AAA (R03) batteries (2)
Wireless LAN card (1)
USB wireless LAN module (IFU-
WLM2) (1)
Design and specifications are subject to change
without notice.
