Sony VPL-ES2 - G Board; Lamp Power Supply

1-10
VPL-CS7/ES2
1-3-13. G Board
. Remove the cover (G), sheet (G). (Refer to 1-3-11)
1-3-14. Lamp Power Supply
. Remove the cover (G), sheet (G). (Refer to 1-3-11)
. Remove the G board. (Refer to 1-3-13.)
C board
2 G board
4 Lamp power supply
1 Flat connector assembly
CN201
CN1
CN2
CN102
CN101
C board
2 Two screws
(+PSW3 x 8)
3 Sheet (B)
1 Two screws
(+BTP3 x 10)
