Installation Diagram
Floor Installation (Front Projection)
a: distance between the screen and the center of the lens
b: distance between the floor and the center of the lens
c: distance between the floor and the bottom of the projector
x: free
Center of the screen
Wall
Floor
Distance between the front of the
cabinet and the center of the lens
Center of the lens
VPLL-ZM100: 109 mm (4
3
/
8
inches)
VPLL-FM30: 85 mm (3
3
/
8
inches)
When using the VPLL-ZM100 2 times Zoom long focus lens
For the VPL-X600U/E/M, VPL-X1000U/E/M
Screen size (inches) 80 100 120 150 180 200 250 300
Minimum
4370 5500 6630 8330 10020 11150 13980 16810
a
(172
1
/
8
) (216
1
/
8
) (261
1
/
8
) (328) (394
1
/
2
) (439) (550
1
/
2
) (661
7
/
8
)
Maximum
8340 10430 12520 15650 18790 20880 26100 31320
(328
3
/
8
) (410
3
/
4
) (493) (616
1
/
4
) (739
7
/
8
) (822
1
/
8
) (1027
5
/
8
) (1233
1
/
8
)
b
x–580 x–725 x–870 x–1088 x–1305 x–1450 x–1813 x–2176
(x–22
7
/
8
) (x–28
5
/
8
) (x–34
3
/
8
) (x–42
7
/
8
) (x–51
1
/
2
) (x–57
1
/
8
) (x–71
1
/
2
) (x–85
3
/
4
)
c
x–663 x–808 x–954 x–1171 x–1389 x–1534 x–1896 x–2259
(x–26
1
/
8
) (x–31
7
/
8
) (x–37
5
/
8
) (x–46
1
/
8
) (x–54
3
/
4
) (x–60
1
/
2
) (x–74
3
/
4
) (x–89)
Unit: mm (inches)
Method of calculation (unit: mm)
SS: Screen size diagonal (inches)
a min = (SS × 72.290/1.31 – 155) × 1.025
a max = (SS × 140.374/1.31 – 20) × 0.975
b = x – SS/1.31 × 9.5
c = x – (SS/1.31 × 9.5 + 83.3)
11
(EN)
For the VPL-S600U/E/M
Screen size (inches) 80 100 120 150 180 200 250 300
Minimum
4550 5720 6900 8660 10430 11600 14540 17480
a
(179
1
/
4
) (225
1
/
4
) (271
3
/
4
) (341) (410
3
/
4
) (456
3
/
4
) (572
1
/
2
) (688
1
/
4
)
Minimum
8670 10840 13020 16270 19530 21710 27140 32570
(341
3
/
8
) (426
7
/
8
) (512
5
/
8
) (640
5
/
8
) (769) (854
3
/
4
) (1068
5
/
8
) (1282
3
/
8
)
b
x–603 x–754 x–905 x–1131 x–1357 x–1508 x–1885 x–2262
(x–23
3
/
4
) (x–29
3
/
4
) (x–35
3
/
4
) (x–44
5
/
8
) (x–53
1
/
2
) (x–59
3
/
8
) (x–74
1
/
4
) (x–89
1
/
8
)
c
x–686 x–837 x–988 x–1214 x–1440 x–1591 x–1968 x–2345
(x–27
1
/
8
) (x–33) (x–39) (x–47
7
/
8
) (x–56
3
/
4
) (x–62
3
/
4
) (x–77
1
/
2
) (x–92
3
/
8
)
Unit: mm (inches)
Method of calculation (unit: mm)
SS: Screen size diagonal (inches)
a min = (SS × 72.290/1.26 – 155) × 1.025
a max = (SS × 140.374/1.26 – 20) × 0.975
b = x – SS/1.26 × 9.5
c = x – (SS/1.26 × 9.5 + 83.3)
XGA/SXGA signal input
a min = (SS × 72.290/1.29 – 155) × 1.025
a max = (SS × 140.374/1.29 – 20) × 0.975
b = x – SS/1.29 × 9.5
c = x – (SS/1.29 × 9.5 + 83.3)
Macintosh 16-inch mode signal (horizontal 832 ×
vertical 624)/HDTV input
Refer to the table of the VPL-X600U/E/M.
For the VPL-S900U/E/M
Screen size (inches) 80 100 120 150 180 200 250 300
Minimum
4400 5540 6680 8400 10110 11250 14100 16950
a
(173
1
/
4
) (218
1
/
4
) (263
1
/
8
) (330
3
/
4
) (398
1
/
8
) (443) (555
1
/
4
) (667
1
/
2
)
Minimum
8410 10510 12620 15780 18940 21050 26320 31580
(331
1
/
4
) (413
7
/
8
) (497) (621
3
/
8
) (745
7
/
8
) (828
7
/
8
) (1036
3
/
8
) (1243
1
/
2
)
b
x–585 x–731 x–877 x–1097 x–1316 x–1462 x–1828 x–2194
(x–23
1
/
8
) (x–28
7
/
8
) (x–34
5
/
8
) (x–43
1
/
4
) (x–51
7
/
8
) (x–57
5
/
8
) (x–72) (x–86
3
/
8
)
c
x–668 x–815 x–961 x–1180 x–1399 x–1546 x–1911 x–2277
(x–26
3
/
8
) (x–32
1
/
8
) (x–37
7
/
8
) (x–46
1
/
2
) (x–55
1
/
8
) (x–60
7
/
8
) (x–75
3
/
8
) (x–89
3
/
4
)
Unit: mm (inches)
Method of calculation (unit: mm)
SS: Screen size diagonal (inches)
a min = (SS × 72.290/1.2992 – 155) × 1.025
a max = (SS × 140.374/1.2992 – 20) × 0.975
b = x – SS/1.2992 × 9.5
c = x – (SS/1.2992 × 9.5 + 83.3)
