Sony VPL-S900E - BA BAA BOARD; BA BAA Board Capacitors, Connectors, and Diodes; BA BAA Board ICs and Transistors

6-6
VPL-S900E, VPL-S900M, VPL-S900U
Rf.NO. PART NO. DESCRIPTION REMARK Rf.NO. PART NO. DESCRIPTION REMARK
R2143 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2144 1-216-295-91 SHORT 0
R2145 1-216-295-91 SHORT 0
R2146 1-216-083-00 RES,CHIP 27K 5% 1/10W
R2147 1-216-025-91 RES,CHIP 100 5% 1/10W
R2148 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2149 1-216-025-91 RES,CHIP 100 5% 1/10W
R2151 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2158 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2159 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2167 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2168 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2186 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R2187 1-216-641-11 METAL CHIP 390 0.50% 1/10W
R2188 1-216-089-91 RES,CHIP 47K 5% 1/10W
R2189 1-216-081-00 RES,CHIP 22K 5% 1/10W
R2190 1-216-655-11 METAL CHIP 1.5K 0.50% 1/10W
R2191 1-216-655-11 METAL CHIP 1.5K 0.50% 1/10W
R2192 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R2193 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R2194 1-216-643-11 METAL CHIP 470 0.50% 1/10W
R2195 1-216-653-11 METAL CHIP 1.2K 0.50% 1/10W
R2196 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2197 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2198 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2199 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2200 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2201 1-216-025-91 RES,CHIP 100 5% 1/10W
R2202 1-216-025-91 RES,CHIP 100 5% 1/10W
R2204 1-216-631-11 METAL CHIP 150 0.50% 1/10W
R2205 1-216-629-11 METAL CHIP 120 0.50% 1/10W
R2206 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R2207 1-216-631-11 METAL CHIP 150 0.50% 1/10W
R2208 1-216-629-11 METAL CHIP 120 0.50% 1/10W
R2209 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R2210 1-216-025-91 RES,CHIP 100 5% 1/10W
R2211 1-216-025-91 RES,CHIP 100 5% 1/10W
R2212 1-216-295-91 SHORT 0
R2213 1-216-295-91 SHORT 0
R2214 1-216-295-91 SHORT 0
R2216 1-216-295-91 SHORT 0
R2217 1-216-295-91 SHORT 0
R2218 1-216-677-11 METAL CHIP 12K 0.50% 1/10W
R2219 1-216-035-00 RES,CHIP 270 5% 1/10W
R2220 1-216-035-00 RES,CHIP 270 5% 1/10W
R2221 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2222 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2223 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2224 1-216-017-91 RES,CHIP 47 5% 1/10W
R2225 1-216-017-91 RES,CHIP 47 5% 1/10W
R2226 1-216-017-91 RES,CHIP 47 5% 1/10W
R2227 1-216-017-91 RES,CHIP 47 5% 1/10W
R2228 1-216-017-91 RES,CHIP 47 5% 1/10W
R2229 1-216-017-91 RES,CHIP 47 5% 1/10W
R2233 1-216-025-91 RES,CHIP 100 5% 1/10W
R2234 1-216-025-91 RES,CHIP 100 5% 1/10W
R2235 1-216-025-91 RES,CHIP 100 5% 1/10W
R2236 1-216-025-91 RES,CHIP 100 5% 1/10W
R2237 1-216-655-11 METAL CHIP 1.5K 0.50% 1/10W
R2238 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R2239 1-216-295-91 SHORT 0
R2241 1-216-001-00 RES,CHIP 10 5% 1/10W
R2242 1-247-807-31 CARBON 100 5% 1/4W
R2243 1-247-807-31 CARBON 100 5% 1/4W
R2301 1-216-089-91 RES,CHIP 47K 5% 1/10W
R2302 1-216-025-91 RES,CHIP 100 5% 1/10W
R2303 1-216-025-91 RES,CHIP 100 5% 1/10W
R2304 1-216-025-91 RES,CHIP 100 5% 1/10W
R2306 1-216-033-00 RES,CHIP 220 5% 1/10W
R2307 1-216-635-11 METAL CHIP 220 0.50% 1/10W
R2308 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2309 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R2310 1-216-037-00 RES,CHIP 330 5% 1/10W
R2311 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2312 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2313 1-216-635-11 METAL CHIP 220 0.50% 1/10W
R2314 1-216-025-91 RES,CHIP 100 5% 1/10W
R2315 1-216-657-11 METAL CHIP 1.8K 0.50% 1/10W
R2316 1-216-657-11 METAL CHIP 1.8K 0.50% 1/10W
R2317 1-216-661-11 METAL CHIP 2.7K 0.50% 1/10W
R2318 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R2319 1-216-025-91 RES,CHIP 100 5% 1/10W
R2320 1-216-041-00 RES,CHIP 470 5% 1/10W
R2321 1-216-025-91 RES,CHIP 100 5% 1/10W
R2406 1-216-625-11 METAL CHIP 82 0.50% 1/10W
R2407 1-216-625-11 METAL CHIP 82 0.50% 1/10W
R2408 1-216-625-11 METAL CHIP 82 0.50% 1/10W
R2501 1-216-025-91 RES,CHIP 100 5% 1/10W
R2502 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2503 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2504 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2505 1-216-025-91 RES,CHIP 100 5% 1/10W
R2506 1-216-025-91 RES,CHIP 100 5% 1/10W
<THERMISTOR>
TH2001 1-809-020-11 THERMISTOR
TH2002 1-809-020-11 THERMISTOR
<CRYSTAL>
X2001 1-579-973-11 VIBRATOR, CRYSTAL (3.575611MHz)
X2002 1-760-191-11 VIBRATOR, CRYSTAL (3.579545MHz)
X2003 1-760-191-11 VIBRATOR, CRYSTAL (4.433619MHz)
*****************************************************************
* A-1135-987-A BAA BOARD, COMPLETE
************************
<CAPACITOR>
C2801 1-128-004-11 ELECT CHIP 10µF 20% 16V
C2802 1-128-004-11 ELECT CHIP 10µF 20% 16V
C2803 1-128-453-21 ELECT CHIP 47µF 20% 6.3V
