Sony VPL-S900E - BA BAA BOARD; BA BAA Board Resistors and Crystals

6-7
VPL-S900E, VPL-S900M, VPL-S900U
Rf.NO. PART NO. DESCRIPTION REMARK Rf.NO. PART NO. DESCRIPTION REMARK
C2804 1-128-453-21 ELECT CHIP 47µF 20% 6.3V
C2805 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C2806 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C2807 1-163-217-11 CERAMIC CHIP 1PF 0.25PF 50V
C2808 1-128-453-21 ELECT CHIP 47µF 20% 6.3V
C2809 1-128-453-21 ELECT CHIP 47µF 20% 6.3V
C2810 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C2811 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C2812 1-163-217-11 CERAMIC CHIP 1PF 0.25PF 50V
C2813 1-128-453-21 ELECT CHIP 47µF 20% 6.3V
C2814 1-128-453-21 ELECT CHIP 47µF 20% 6.3V
C2815 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C2816 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C2817 1-128-004-11 ELECT CHIP 10µF 20% 16V
C2818 1-163-217-11 CERAMIC CHIP 1PF 0.25PF 50V
C2819 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C2820 1-128-004-11 ELECT CHIP 10µF 20% 16V
C2821 1-128-004-11 ELECT CHIP 10µF 20% 16V
C2822 1-128-013-11 ELECT CHIP 1µF 20% 50V
C2823 1-128-004-11 ELECT CHIP 10µF 20% 16V
C2824 1-126-204-11 ELECT CHIP 47µF 20% 16V
C2825 1-126-204-11 ELECT CHIP 47µF 20% 16V
C2826 1-128-004-11 ELECT CHIP 10µF 20% 16V
C2827 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C2828 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C2829 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C2830 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C2831 1-128-004-11 ELECT CHIP 10µF 20% 16V
C2832 1-128-013-11 ELECT CHIP 1µF 20% 50V
C2833 1-126-204-11 ELECT CHIP 47µF 20% 16V
<CONNECTOR>
CN2801 * 1-785-237-21 CONNECTOR, BOARD TO BOARD 28P
CN2802 * 1-580-056-21 PIN, CONNECTOR (SMD) 3P
CN2803 * 1-785-762-21 CONNECTOR, BOARD TO BOARD 18P
<DIODE>
D2801 8-719-914-43 DIODE DAN202K
D2802 8-719-800-76 DIODE 1SS226
D2803 8-719-800-76 DIODE 1SS226
D2804 8-719-800-76 DIODE 1SS226
D2805 8-719-158-37 DIODE RD9.1SB2
D2806 8-719-800-76 DIODE 1SS226
D2807 8-719-914-43 DIODE DAN202K
D2808 8-719-800-76 DIODE 1SS226
D2809 8-719-914-43 DIODE DAN202K
D2810 8-719-800-76 DIODE 1SS226
D2811 8-719-800-76 DIODE 1SS226
D2812 8-719-800-76 DIODE 1SS226
D2813 8-719-800-76 DIODE 1SS226
D2814 8-719-800-76 DIODE 1SS226
<IC>
IC2801 8-759-542-11 IC MAX4223ESA-TG06
IC2802 8-759-542-11 IC MAX4223ESA-TG06
IC2803 8-759-542-11 IC MAX4223ESA-TG06
IC2805 8-759-090-19 IC SN75453BPS
IC2806 8-759-092-82 IC SN75157PS-ELL2000
IC2807 8-759-981-48 IC TL082M
<COIL>
L2801 1-412-058-11 INDUCTOR CHIP 10µH
L2802 1-412-058-11 INDUCTOR CHIP 10µH
L2803 1-412-058-11 INDUCTOR CHIP 10µH
<TRANSISTOR>
Q2801 8-729-900-53 TRANSISTOR DTC114EK
Q2802 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2803 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2804 8-729-216-22 TRANSISTOR 2SA1162-G
Q2805 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2806 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2807 8-729-216-22 TRANSISTOR 2SA1162-G
Q2808 8-729-900-53 TRANSISTOR DTC114EK
Q2809 8-729-900-53 TRANSISTOR DTC114EK
<RESISTOR>
R2801 1-216-635-11 METAL CHIP 220 0.50% 1/10W
R2802 1-216-001-00 RES,CHIP 10 5% 1/10W
R2803 1-216-624-11 METAL CHIP 75 0.50% 1/10W
R2804 1-216-089-91 RES,CHIP 47K 5% 1/10W
R2805 1-216-089-91 RES,CHIP 47K 5% 1/10W
R2806 1-216-295-91 SHORT 0
R2807 1-216-635-11 METAL CHIP 220 0.50% 1/10W
R2808 1-216-635-11 METAL CHIP 220 0.50% 1/10W
R2809 1-216-089-91 RES,CHIP 47K 5% 1/10W
R2810 1-216-001-00 RES,CHIP 10 5% 1/10W
R2811 1-216-624-11 METAL CHIP 75 0.50% 1/10W
R2812 1-216-089-91 RES,CHIP 47K 5% 1/10W
R2813 1-216-295-91 SHORT 0
R2814 1-216-635-11 METAL CHIP 220 0.50% 1/10W
R2815 1-216-635-11 METAL CHIP 220 0.50% 1/10W
R2816 1-216-089-91 RES,CHIP 47K 5% 1/10W
R2817 1-216-001-00 RES,CHIP 10 5% 1/10W
R2818 1-216-624-11 METAL CHIP 75 0.50% 1/10W
R2819 1-216-089-91 RES,CHIP 47K 5% 1/10W
R2820 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2821 1-216-295-91 SHORT 0
R2822 1-216-635-11 METAL CHIP 220 0.50% 1/10W
R2824 1-216-089-91 RES,CHIP 47K 5% 1/10W
R2825 1-216-097-91 RES,CHIP 100K 5% 1/10W
R2826 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2827 1-216-025-91 RES,CHIP 100 5% 1/10W
R2828 1-216-097-91 RES,CHIP 100K 5% 1/10W
R2830 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2831 1-216-041-00 RES,CHIP 470 5% 1/10W
R2832 1-216-089-91 RES,CHIP 47K 5% 1/10W
R2833 1-216-001-00 RES,CHIP 10 5% 1/10W
R2834 1-216-186-00 RES,CHIP 330 5% 1/8W
R2835 1-216-186-00 RES,CHIP 330 5% 1/8W
