Rf.NO. PART NO. DESCRIPTION REMARK Rf.NO. PART NO. DESCRIPTION REMARK
* A-1375-172-A H BOARD, COMPLETE
*********************
<CONNECTOR>
CN6001 * 1-764-007-11 PIN, CONNECTOR (SMD) 12P
CN6002 * 1-580-789-21 PIN, CONNECTOR (SMD) 6P
CN6003 * 1-580-057-11 PIN, CONNECTOR (SMD) 4P
CN6004 * 1-580-055-21 PIN, CONNECTOR (SMD) 2P
<DIODE>
D6001 8-719-914-43 DIODE DAN202K
D6002 8-719-914-44 DIODE DAP202K
D6003 8-719-045-61 DIODE SEC1901C
D6004 8-719-045-61 DIODE SEC1901C
D6005 8-719-045-55 DIODE SEC1201C
D6006 8-719-045-60 DIODE SEC1401C
D6007 8-719-045-53 DIODE SEC1801C
D6008 8-719-914-43 DIODE DAN202K
D6009 8-719-914-43 DIODE DAN202K
D6010 8-719-914-43 DIODE DAN202K
D6011 8-719-914-44 DIODE DAP202K
D6012 8-719-914-44 DIODE DAP202K
D6013 8-719-914-44 DIODE DAP202K
D6014 8-719-045-60 DIODE SEC1401C
D6015 8-719-045-53 DIODE SEC1801C
D6016 8-719-045-53 DIODE SEC1801C
D6017 8-719-045-53 DIODE SEC1801C
D6018 8-719-045-53 DIODE SEC1801C
D6019 8-719-045-53 DIODE SEC1801C
D6020 8-719-045-53 DIODE SEC1801C
D6021 8-719-045-53 DIODE SEC1801C
D6022 8-719-045-53 DIODE SEC1801C
D6023 8-719-045-53 DIODE SEC1801C
D6024 8-719-045-53 DIODE SEC1801C
D6025 8-719-045-53 DIODE SEC1801C
D6026 8-719-045-53 DIODE SEC1801C
D6027 8-719-045-53 DIODE SEC1801C
D6028 8-719-045-53 DIODE SEC1801C
<TRANSISTOR>
Q6001 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q6002 8-729-230-49 TRANSISTOR 2SC2712-YG
Q6005 8-729-230-49 TRANSISTOR 2SC2712-YG
<RESISTOR>
R6001 1-216-083-00 RES,CHIP 27K 5% 1/10W
R6002 1-216-075-00 RES,CHIP 12K 5% 1/10W
R6003 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R6004 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R6005 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R6006 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R6007 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R6008 1-216-055-00 RES,CHIP 1.8K 5% 1/10W
R6009 1-216-073-00 RES,CHIP 10K 5% 1/10W
R6010 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R6011 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R6012 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R6013 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R6014 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R6015 1-216-055-00 RES,CHIP 1.8K 5% 1/10W
R6016 1-216-073-00 RES,CHIP 10K 5% 1/10W
R6017 1-216-049-91 RES,CHIP 1K 5% 1/10W
R6018 1-216-037-00 RES,CHIP 330 5% 1/10W
R6019 1-216-075-00 RES,CHIP 12K 5% 1/10W
R6020 1-216-033-00 RES,CHIP 220 5% 1/10W
R6021 1-216-039-00 RES,CHIP 390 5% 1/10W
R6022 1-216-029-00 RES,CHIP 150 5% 1/10W
R6024 1-216-029-00 RES,CHIP 150 5% 1/10W
R6026 1-216-029-00 RES,CHIP 150 5% 1/10W
R6028 1-216-029-00 RES,CHIP 150 5% 1/10W
R6030 1-216-029-00 RES,CHIP 150 5% 1/10W
R6033 1-216-029-00 RES,CHIP 150 5% 1/10W
R6034 1-216-039-00 RES,CHIP 390 5% 1/10W
R6035 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R6038 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
<SWITCH>
S6001 1-692-453-11 SWITCH, KEY BOARD (?(LEFT))
S6002 1-692-453-11 SWITCH, KEY BOARD (/(RIGHT))
S6003 1-692-453-11 SWITCH, KEY BOARD (.(DOWN))
S6004 1-692-453-11 SWITCH, KEY BOARD (>(UP))
S6005 1-692-453-11 SWITCH, KEY BOARD (ENTER)
S6006 1-692-453-11 SWITCH, KEY BOARD (MENU)
S6007 1-692-453-11 SWITCH, KEY BOARD (INPUT)
S6008 1-692-453-11 SWITCH, KEY BOARD (POWER)
S6009 1-692-453-11 SWITCH, KEY BOARD (PATTERN)
S6010 1-692-453-11 SWITCH, KEY BOARD (AUTO)
S6011 1-692-453-11 SWITCH, KEY BOARD (VOLUME –)
S6012 1-692-453-11 SWITCH, KEY BOARD (VOLUME +)
S6013 1-692-453-11 SWITCH, KEY BOARD (RESET)
S6014 1-692-453-11 SWITCH, KEY BOARD (LIGHT)
*****************************************************************
* 1-668-126-11 NF BOARD
**********
<CAPACITOR>
C4007 1-124-589-11 ELECT 47µF 20% 10V
<CONNECTOR>
CN4001 * 1-564-518-11 PLUG, CONNECTOR 3P
<IC>
IC4001 8-749-011-03 IC GP1U26X
H
NF
