Sony VPL-S900E - BB BOARD; BB Board (1;6) - Memory Control (R)

6-20
VPL-S900E, VPL-S900M, VPL-S900U
Rf.NO. PART NO. DESCRIPTION REMARK Rf.NO. PART NO. DESCRIPTION REMARK
<RESISTOR>
R4001 1-216-017-91 RES,CHIP 47 5% 1/10W
R4002 1-216-025-91 RES,CHIP 100 5% 1/10W
*****************************************************************
* 1-668-127-11 NR BOARD
**********
<CAPACITOR>
C4801 1-124-589-11 ELECT 47µF 20% 10V
<CONNECTOR>
CN4801 * 1-564-518-11 PLUG, CONNECTOR 3P
<IC>
IC4801 8-749-011-03 IC GP1U26X
<RESISTOR>
R4801 1-216-017-91 RES,CHIP 47 5% 1/10W
R4802 1-216-025-91 RES,CHIP 100 5% 1/10W
*****************************************************************
* A-1275-150-D QA BOARD, COMPLETE
***********************
<CAPACITOR>
C1001 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C1003 1-126-603-11 ELECT CHIP 4.7µF 20% 35V
C1005 1-126-603-11 ELECT CHIP 4.7µF 20% 35V
C1006 1-126-603-11 ELECT CHIP 4.7µF 20% 35V
C1007 1-126-603-11 ELECT CHIP 4.7µF 20% 35V
C1008 1-126-191-11 ELECT CHIP 0.47µF 20% 50V
C1009 1-126-191-11 ELECT CHIP 0.47µF 20% 50V
C1010 1-115-565-11 CERAMIC CHIP 2.2µF 10% 10V
C1011 1-115-565-11 CERAMIC CHIP 2.2µF 10% 10V
C1012 1-124-779-00 ELECT CHIP 10µF 20% 16V
C1024 1-124-779-00 ELECT CHIP 10µF 20% 16V
C1030 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1040 1-107-682-11 CERAMIC CHIP 1µF 10% 16V
C1041 1-107-682-11 CERAMIC CHIP 1µF 10% 16V
C1048 1-126-395-11 ELECT CHIP 22µF 20% 16V
C1049 1-126-395-11 ELECT CHIP 22µF 20% 16V
C1050 1-126-601-11 ELECT CHIP 2.2µF 20% 50V
C1051 1-117-681-11 ELECT CHIP 100µF 20% 16V
C1052 1-107-682-11 CERAMIC CHIP 1µF 10% 16V
C1053 1-117-681-11 ELECT CHIP 100µF 20% 16V
C1054 1-117-681-11 ELECT CHIP 100µF 20% 16V
C1055 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C1056 1-117-681-11 ELECT CHIP 100µF 20% 16V
C1057 1-117-681-11 ELECT CHIP 100µF 20% 16V
C1058 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C1059 1-117-681-11 ELECT CHIP 100µF 20% 16V
C1060 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1061 1-126-603-11 ELECT CHIP 4.7µF 20% 35V
C1062 1-126-603-11 ELECT CHIP 4.7µF 20% 35V
C1065 1-164-161-11 CERAMIC CHIP 0.0022µF10% 50V
C1066 1-124-779-00 ELECT CHIP 10µF 20% 16V
C1068 1-107-682-11 CERAMIC CHIP 1µF 10% 16V
C1069 1-124-779-00 ELECT CHIP 10µF 20% 16V
C1072 1-124-779-00 ELECT CHIP 10µF 20% 16V
C1073 1-164-161-11 CERAMIC CHIP 0.0022µF10% 50V
C1074 1-124-779-00 ELECT CHIP 10µF 20% 16V
C1075 1-107-682-11 CERAMIC CHIP 1µF 10% 16V
C1077 1-117-681-11 ELECT CHIP 100µF 20% 16V
C1078 1-124-779-00 ELECT CHIP 10µF 20% 16V
C1079 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1080 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1081 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1082 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1083 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1084 1-124-779-00 ELECT CHIP 10µF 20% 16V
C1085 1-124-779-00 ELECT CHIP 10µF 20% 16V
C1086 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C1087 1-107-682-11 CERAMIC CHIP 1µF 10% 16V
C1088 1-126-204-11 ELECT CHIP 47µF 20% 16V
C1089 1-126-204-11 ELECT CHIP 47µF 20% 16V
C1090 1-163-023-00 CERAMIC CHIP 0.015µF 10% 50V
C1091 1-163-023-00 CERAMIC CHIP 0.015µF 10% 50V
C1092 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1093 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1094 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1095 1-107-682-11 CERAMIC CHIP 1µF 10% 16V
C1096 1-107-682-11 CERAMIC CHIP 1µF 10% 16V
C1097 1-107-682-11 CERAMIC CHIP 1µF 10% 16V
<CONNECTOR>
CN1001 * 1-580-789-21 PIN, CONNECTOR (SMD) 6P
CN1002 * 1-569-775-21 PIN, CONNECTOR (SMD) 5P
CN1003 * 1-580-057-11 PIN, CONNECTOR (SMD) 4P
CN1004 * 1-764-007-11 PIN, CONNECTOR (SMD) 12P
<DIODE>
D1001 8-719-158-37 DIODE RD9.1SB2
D1002 8-719-158-37 DIODE RD9.1SB2
D1003 8-719-158-37 DIODE RD9.1SB2
D1004 8-719-158-37 DIODE RD9.1SB2
D1005 8-719-158-37 DIODE RD9.1SB2
D1007 8-719-158-37 DIODE RD9.1SB2
D1008 8-719-158-37 DIODE RD9.1SB2
D1009 8-719-914-43 DIODE DAN202K
D1010 8-719-914-44 DIODE DAP202K
D1011 8-719-036-76 DIODE RD3.3SB2-T1
D1012 8-719-914-43 DIODE DAN202K
D1013 8-719-914-43 DIODE DAN202K
D1014 8-719-158-37 DIODE RD9.1SB2
D1015 8-719-158-37 DIODE RD9.1SB2
NF NR QA
