31 (GB)
Attaching the projector suspension support PSS-610
When installing the projector on the ceiling, use the
PSS-610 Projector Suspension Support. For more
details on the ceiling installation, refer to the
Installation manual for Dealers of the PSS-610. The
installation measurements are shown below when you
install the projector on the ceiling.
Installation Diagram
Top view
Align the center of the lens with the center of the screen.
Front of the cabinet
Distance between the screen
and the center of the lens
Center of the unit
Center of the screen
Center of the lens
Center of the supporting pole
(The center of the supporting pole is
different from that of the unit.)
Upper ceiling mount bracket
Front view
The lens is offset 40 mm (1
9
/16 inch) to the right
from the center of the supporting pole. When
mounting, take care to align the center of the lens
with the center of the screen; not the center of the
supporting pole.
Center
of the
supporting
pole
Center of
the unit
The bottom
surface of the
mount bracket
Distance between the ceiling and the
surface of the mount bracket
Using adjustment pipe (b):
150/175/200 mm (6/7/7
1
/8 inches)
Using adjustment pipe (c):
250/275/300 mm (9
7
/8/10
7
/8/11
7
/8 inches)
Ceiling
Side view
Units: mm (inches)
Rear of the
lens
Front of the
lens
Installation Examples
208.5
(8
7
/
32
)
126.3
(4
31
/
32
)
216.6
(8
17
/
32
)
157.5
(6
3
/
16
)
40
(1
9
/
16
)
125
(4
29
/
32
)
96.5
(3
13
/
16
)
250
(9
27
/
32
)
157.5
(6
3
/
16
)
40
(1
9
/
16
)
208.5
(8
7
/32)
198.4
(7
13
/16)
126.3
(4
31
/32)
216.6
(8
17
/32)
219.6
(8
21
/32)
Units: mm (inches)
Center
of the
lens
Front of the
cabinet
To Next Page
