Locating controls
For details about each part, refer to the pages in parentheses.
Rear sideFront side
1
2
3
5
6
4
7
8
9
0
qa
1 Shuttle switch
(pages 17 to 22, 25, 27 to 39)
2 Nx button
(pages 14 to 25, 27 to 29, 31 to 39)
3 SEARCH/MENU button
(pages 15, 17 to 25, 27 to 29, 31 to 39)
4 Display (pages 10, 15, 22, 26)
For details on the display and icons,
refer to page 10.
5 VOL (Volume) +/– button (pages 14,
33)
6 DISPLAY button (pages 26 to 27)
7 REPEAT/SOUND button
(pages 22 to 24, 28)
8 Strap hole
9 Headphone jack (page 14)
q; Reset button (page 42)
qa USB jack (page 12)
