Sony WH1000XM4/SMIN Service Manual

WH-1000XM4
24
Sony CONFIDENTIAL
For Authorized Servicer
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
SET
2-5. BATTERY WIRE CONNECTOR (R-ch)
(Page 28)
2-2. EARPAD ASSY
(Page 25)
2-4. SCREEN (R) (R-ch)
(Page 27)
L-ch
Headband
R-ch
2-16. NFC L BOARD
(Page 39)
2-17. MAIN L BOARD-1
(Page 40)
2-18. MAIN L BOARD-2
(Page 41)
2-19. MAIN L BOARD-3
(Page 42)
2-15. HOW TO INSTALL
THE ORNAMENT
L ASSY
(Page 38)
2-7. THM R BOARD
(Page 30)
2-9. SUB R BOARD-1
(Page 32)
2-10. SUB R BOARD-2
(Page 33)
2-11. SUB R BOARD-3
(Page 34)
2-8. LITHIUM ION
STORAGE
BATTERY
(Page 31)
2-12. HOUSING (R) BLOCK,
AORI CUSHION
(Page 35)
2-3. HOW TO INSTALL
THE EARPAD ASSY
(Page 26)
2-6. ORNAMENT R ASSY
(Page 29)
2-7. THM R BOARD
(Page 30)
2-9. SUB R BOARD-1
(Page 32)
2-10. SUB R BOARD-2
(Page 33)
2-11. SUB R BOARD-3
(Page 34)
2-12. HOUSING (R) BLOCK,
AORI CUSHION
(Page 35)
2-6. ORNAMENT R ASSY
(Page 29)
2-20. HOUSING (L) BLOCK,
AORI CUSHION-1
(Page 43)
2-21. HOUSING (L) BLOCK,
AORI CUSHION-2
(Page 44)
2-14. ORNAMENT L ASSY
(Page 37)
2-13. SCREEN (L)
(Page 36)
2-14. ORNAMENT L ASSY
(Page 37)
2-13. SCREEN (L)
(Page 36)
2-20. HOUSING (L) BLOCK,
AORI CUSHION-1
(Page 43)
2-21. HOUSING (L) BLOCK,
AORI CUSHION-2
(Page 44)
Note: Please detach the cable (with plug) beforehand.
•
JIG
When disassembling the unit, use the following jig.
Part No. Description
991340233 TOOL FOR DISASSEMBLING
SYSSET
2020/09/0901:17:45(GMT+09:00)
