Sony WM-FX855 - 6 Diagrams; AUDIO Section

– 21 –
• Waveforms
– AUDIO Section –
– TUNER Section –
1 IC501 @ª (XIN)
1V/DIV, 10 µs/DIV
2 IC701 5 (X0)
2V/DIV, 200 ns/DIV
1 T3 4
1V/DIV, 100 ns/DIV
2 T3 1
10V/DIV, 100 ns/DIV
2.4 Vp-p
2 ns
20.4 Vp-p
18 ns
1.8 Vp-p
75 kHz
4 Vp-p
4 MHz
