Sony WM-FX855 - 3 Disassembly

– 6 –
CASE ASS’Y
SECTION 3
DISASSEMBLY
AUDIO BOARD
• This set can be disassembled in the order shown below.
1 two screws
(IB lock)
3 Remove the case ass’y
to direction of the arrow
A .
2 two screws
(IB lock)
2 screw (IB lock)
6 two screws
(M1.7
× 3.0)
3 Remove four solders.
5 Remove four solders.
2 tuner flexible board
9 sw cover
8 AUDIO board
4 Remove two solders.
7 screw
(IB lock)
1 head flexible board
CASE ASS’Y
(page 6)
AUDIO BOARD
(page 6)
MECHANISM DEC
K
(page 7)
LID ASS’Y CASSETTE
(page 7)
Note: Follow the disassembly procedure in the numerical order given.
