– 37 –
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remark
AUDIO
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
A-3061-553-A AUDIO BOARD, COMPLETE
**********************
< CAPACITOR >
C103 1-117-181-11 TANTAL. CHIP 4.7uF 20% 2.5V
C104 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C105 1-115-156-11 CERAMIC CHIP 1uF 10V
C106 1-162-965-11 CERAMIC CHIP 0.0015uF10% 50V
C107 1-164-174-11 CERAMIC CHIP 0.0082uF10% 25V
C108 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C109 1-115-156-11 CERAMIC CHIP 1uF 10V
C110 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C111 1-109-936-11 TANTAL. CHIP 3.3uF 20% 2.5V
C112 1-115-156-11 CERAMIC CHIP 1uF 10V
C113 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C114 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C116 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C117 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C118 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C203 1-117-181-11 TANTAL. CHIP 4.7uF 20% 2.5V
C204 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C205 1-115-156-11 CERAMIC CHIP 1uF 10V
C206 1-162-965-11 CERAMIC CHIP 0.0015uF10% 50V
C207 1-164-174-11 CERAMIC CHIP 0.0082uF10% 25V
C208 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C209 1-115-156-11 CERAMIC CHIP 1uF 10V
C210 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C211 1-109-936-11 TANTAL. CHIP 3.3uF 20% 2.5V
C212 1-115-156-11 CERAMIC CHIP 1uF 10V
C213 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C214 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C216 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C217 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C218 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C301 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C302 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C303 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C304 1-109-935-11 TANTAL. CHIP 4.7uF 20% 6.3V
C305 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C306 1-164-947-11 CERAMIC CHIP 0.01uF 16V
C307 1-107-815-11 TANTAL. CHIP 2.2uF 20% 4V
C308 1-117-181-11 TANTAL. CHIP 4.7uF 20% 2.5V
C309 1-117-578-11 TANTAL. CHIP 470uF 20% 2.5V
C310 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C311 1-107-983-11 TANTAL. CHIP 10uF 20% 2.5V
C312 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C313 1-117-181-11 TANTAL. CHIP 4.7uF 20% 2.5V
C314 1-115-156-11 CERAMIC CHIP 1uF 10V
C315 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C317 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C318 1-117-181-11 TANTAL. CHIP 4.7uF 20% 2.5V
C319 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C320 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C321 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C501 1-164-858-11 CERAMIC CHIP 22PF 5% 16V
C502 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C503 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C504 1-164-854-11 CERAMIC CHIP 15PF 5% 16V
C505 1-164-854-11 CERAMIC CHIP 15PF 5% 16V
C506 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C507 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C508 1-164-947-11 CERAMIC CHIP 0.01uF 16V
C509 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C510 1-164-858-11 CERAMIC CHIP 22PF 5% 16V
C511 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C512 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C513 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C514 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C515 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C518 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V
C519 1-164-850-11 CERAMIC CHIP 18PF 5% 16V
C601 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C602 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C603 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C604 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C605 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C606 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C607 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C608 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C701 1-115-156-11 CERAMIC CHIP 1uF 10V
C702 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C703 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C706 1-115-156-11 CERAMIC CHIP 1uF 10V
To Next Page
