– 38 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C707 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C801 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C802 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C803 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C804 1-109-935-11 TANTAL. CHIP 4.7uF 20% 6.3V
C805 1-107-685-11 TANTAL. CHIP 15uF 20% 6.3V
C807 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
CB301 1-117-968-11 CERAMIC CHIP 680PF 50V
< CONNECTOR >
CN301 1-766-336-21 CONNECTOR, FFC/FPC 6P
CN501 1-766-350-21 CONNECTOR, FFC/FPC 20P
< DIODE >
D101 8-719-977-37 DIODE DTZ12C
D201 8-719-977-37 DIODE DTZ12C
D501 8-719-051-01 LED CL-170HR-CD-T (BATT)
D502 8-719-977-37 DIODE DTZ12C
D701 8-719-404-49 DIODE MA111
< FERRITE BEAD >
FB701 1-414-385-11 INDUCTOR 0uH
FB702 1-414-385-11 INDUCTOR 0uH
FB703 1-414-385-11 INDUCTOR 0uH
FB704 1-414-385-11 INDUCTOR 0uH
< IC >
IC301 8-759-440-52 IC TA2103F
IC501 8-759-446-30 IC uPD17073GB-912-9EV
IC502 8-759-499-37 IC AK93C55-S
IC601 8-759-356-46 IC MM1279XVBE
IC701 8-759-483-50 IC MB89133LPFV-G-418BND
IC703 8-759-280-85 IC PST9010NL
IC704 8-759-460-26 IC PST9015NL
IC801 8-759-440-53 IC MPC1850DTBEL
< JACK >
J301 1-779-867-11 JACK (2REMOTE)
< COIL >
L101 1-410-997-31 INDUCTOR CHIP 2.2uH
L201 1-410-997-31 INDUCTOR CHIP 2.2uH
L301 1-412-006-31 INDUCTOR CHIP 10uH
L302 1-410-997-31 INDUCTOR CHIP 2.2uH
L501 1-412-006-31 INDUCTOR CHIP 10uH
L502 1-412-975-31 INDUCTOR 0.47uH
L503 1-412-967-31 INDUCTOR 0.1uH
< LIQUID CRYSTAL DISPLAY >
ND501 1-801-894-11 DISPLAY PANEL, LIQUID CRYSTAL
< PHOTO REFLECTOR >
PH701 8-719-988-15 PHTO REFLECTOR PR-11-C
< TRANSISTOR >
Q301 8-729-800-71 TRANSISTOR 2SB815B7-TB
Q302 8-729-040-12 TRANSISTOR MUN5215T1
Q303 8-729-422-39 TRANSISTOR XN4404
Q306 8-729-420-50 TRANSISTOR UN5215
Q308 8-729-420-50 TRANSISTOR UN5215
Q501 8-729-040-12 TRANSISTOR MUN5215T1
Q502 8-729-800-71 TRANSISTOR 2SB815B7-TB
Q503 8-729-423-52 TRANSISTOR 2SC3931-C
Q504 8-729-423-52 TRANSISTOR 2SC3931-C
Q505 8-729-040-12 TRANSISTOR MUN5215T1
Q506 8-729-040-12 TRANSISTOR MUN5215T1
Q601 8-729-403-42 TRANSISTOR XN1401
Q602 8-729-402-84 TRANSISTOR XN4601
Q701 8-729-230-72 TRANSISTOR 2SA1362YG
Q702 8-729-421-29 TRANSISTOR UN5216R
Q703 8-729-800-71 TRANSISTOR 2SB815B7-TB
Q704 8-729-425-46 TRANSISTOR XP4315-TXE
Q705 8-729-422-54 TRANSISTOR XN4215
Q706 8-729-421-29 TRANSISTOR UN5216R
Q707 8-729-230-72 TRANSISTOR 2SA1362YG
< RESISTOR >
R101 1-218-944-11 METAL CHIP 180 5% 1/16W
R102 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
R103 1-218-270-11 METAL CHIP 1.1K 5% 1/16W
R104 1-218-966-11 METAL CHIP 12K 5% 1/16W
R105 1-218-984-11 METAL CHIP 390K 5% 1/16W
R106 1-218-953-11 METAL CHIP 1.0K 5% 1/16W
R107 1-216-793-11 METAL CHIP 4.7 5% 1/16W
R108 1-218-941-11 METAL CHIP 100 5% 1/16W
R110 1-216-844-11 METAL CHIP 82K 5% 1/16W
R111 1-218-980-11 METAL CHIP 180K 5% 1/16W
R112 1-218-979-11 METAL CHIP 150K 5% 1/16W
R113 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R114 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R115 1-218-971-11 METAL CHIP 33K 5% 1/16W
R116 1-218-971-11 METAL CHIP 33K 5% 1/16W
R201 1-218-944-11 METAL CHIP 180 5% 1/16W
R202 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
R203 1-218-270-11 METAL CHIP 1.1K 5% 1/16W
R204 1-218-966-11 METAL CHIP 12K 5% 1/16W
R205 1-218-984-11 METAL CHIP 390K 5% 1/16W
R206 1-218-953-11 METAL CHIP 1.0K 5% 1/16W
R207 1-216-793-11 METAL CHIP 4.7 5% 1/16W
R208 1-218-941-11 METAL CHIP 100 5% 1/16W
R210 1-216-844-11 METAL CHIP 82K 5% 1/16W
R211 1-218-980-11 METAL CHIP 180K 5% 1/16W
R212 1-218-979-11 METAL CHIP 150K 5% 1/16W
R213 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R214 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R215 1-218-971-11 METAL CHIP 33K 5% 1/16W
R216 1-218-971-11 METAL CHIP 33K 5% 1/16W
R301 1-218-891-11 METAL CHIP 68K 0.5% 1/16W
R302 1-218-969-11 METAL CHIP 22K 5% 1/16W
R304 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R305 1-218-295-11 METAL CHIP 43K 5% 1/16W
R307 1-216-793-11 METAL CHIP 4.7 5% 1/16W
R308 1-218-981-11 METAL CHIP 220K 5% 1/16W
R309 1-218-969-11 METAL CHIP 22K 5% 1/16W
AUDIO
Ver 1.3
