SECTION 2
GENERAL
LOCATION AND FUNCTION OF CONTROLS
Tape player section and general
• Main Unit
Radio section
• Main Unit
• Headphones with Remote Control
Left Right
• Headphones with Remote Control
Left Right
1 OPEN button
2 Information display
3 Contact for dry battery case
4 Rechargeable battery case
5 Tape operation buttons
6 BATT indicator
7 HOLD switch
8 Main unit : VOLUME knob
Remote control : VOL knob
9 Åa (Tape direction),
BL SKIP (Blank skip) switch
!º a(DOLBY) NR switch
!¡ 2 REMOTE jack
!™ Micro plug
!£ SOUND/AVLS button
1 ENTER button
2 ASP (Auto Station Preset) button
3 PRESET +, – button
4 TUNE +, – button
5 p, RADIO OFF button
6 FM ST/MONO switch
7 BAND, RADIO ON button
