6. Unhook the top row hooks. (8 hooks)
12
REAR COVER
TOOLS & EQUIPMENTS FFC PRECAUTIONS SECTION 1 SECTION 2 SECTION 3 SMART CORE APPENDIX
① Tilt the rear cover and push upwards on the left/right side.
② Lift the rear cover off from the center
Legend
=outline hook
1
2
1-1. DISASSEMBLY AND REMOVAL CAUTION
SECTION 1: XR-55A8*K
