1 LIST OF ITEMS TO BRING
1. Screwdriver (e.g., #2 Phillips Screwdriver)
2. Multimeter
3. ESD Wrist Straps
4. Metal Washer (Flat) or Coin (for remove Rear Cover)
5. Ruler (for remove Rear Cover)
6. Service Manual (Unique) (for remove & replace details)
2 OPTIONAL EQUIPMENT
1. Screwdriver (e.g., #0 Phillips Screwdriver)
2. Parts Tray for loose screws and small items
2. Flashlight
3. Service Manual (Common) (for t/shooting information)
For Surface Mounted Parts/Connectors:
Hot-Air Type soldering Iron is needed.
Thickness: approx. 1.5mm
Diameter: 20~25mm
(wrap in tape (L=50mm))
Plastic or Metal Ruler
(In case of Metal ruler, wrap in tape
(L=50mm) for prevent scratches)
TOOLS & EQUIPMENT
3

Sony XR-83A90J Specifications

General

Screen Size	83 inches
Display Type	OLED
HDR	HDR10, Dolby Vision, HLG
Processor	Cognitive Processor XR
Operating System	Google TV
HDMI Ports	4
USB Ports	3
Variable Refresh Rate (VRR)	Yes
Auto Low Latency Mode (ALLM)	Yes
eARC	Yes
Refresh Rate	120Hz
Voice Assistants	Google Assistant, Amazon Alexa
Speaker Configuration	2.2 channel
Resolution	3840 x 2160
Wi-Fi	Yes (802.11a/b/g/n/ac)
Bluetooth	Bluetooth 4.2
Audio Output	20W + 10W + 10W
