– 10 –
CO
VER ASS’Y
FRONT P
ANEL ASS’Y
Note:
Follo
w the disassembly procedur
e in the numerical order gi
ven.
SECTION 2
DISASSEMBL
Y
1
claw
3
cov
er ass’y
2
three claws
1
claw
4
front panel ass’y
3
Push the bearing (L).
2
Push the bearing (R).
1
Push the button (OPEN).
