– 44 –
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Abbreviation
G : German
SE : South European
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remark
KEY
When indicating parts by reference
number, please include the board.
KEY BOARD
**********
* 3-023-162-01 PLATE (LCD), LIGHT GUIDE
* 3-023-163-01 HOLDER (LCD)
* 3-023-221-01 ILLUMINATOR (LCD)
< CAPACITOR >
C770 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C771 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C772 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN701 1-778-183-11 PLUG, CONNECTOR 18P
< DIODE >
D710 8-719-421-36 DIODE MA8036-L
D770 8-719-420-90 DIODE MA8051-M
D771 8-719-420-90 DIODE MA8051-M
D773 8-719-404-49 DIODE MA111
< IC >
IC701 8-759-474-47 IC uPD16432BGC-011-9EU
IC702 8-749-012-17 IC RS-140-T
< LIQUID CRYSTAL DISPLAY >
LCD701 1-801-679-11 DISPLAY PANEL, LIQUID CRYSTAL
< DIODE >
LED761 8-719-987-45 LED CL-155Y/PG-CD
LED762 8-719-987-45 LED CL-155Y/PG-CD
LED763 8-719-987-45 LED CL-155Y/PG-CD
LED764 8-719-987-45 LED CL-155Y/PG-CD
LED765 8-719-987-45 LED CL-155Y/PG-CD
LED766 8-719-987-45 LED CL-155Y/PG-CD
LED773 8-719-033-14 LED CL-170PG-CD-T
LED774 8-719-033-13 LED CL-170Y-CD-T
< SWITCH >
LSW700 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (OFF)
LSW701 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (SOURCE)
LSW702 1-762-620-11 SWITCH, KEY BOARD (WITH LED)
(SEEK/AMS, = 0/–)
LSW703 1-762-620-11 SWITCH, KEY BOARD (WITH LED)
(MODE *)
LSW704 1-762-620-11 SWITCH, KEY BOARD (WITH LED)
(SEEK/AMS, + )/+)
LSW705 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (SOUND)
LSW706 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (SHIFT)
LSW707 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (1)
LSW708 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (2)
LSW709 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (3)
LSW710 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (4)
LSW711 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (DSPL)
LSW712 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (LIST)
LSW713 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (AF/TA)
LSW715 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (10)
LSW716 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (9)
LSW717 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (8)
LSW718 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (7)
LSW719 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (6)
LSW720 1-762-620-11 SWITCH, KEY BOARD (WITH LED) (5)
< PILOT LAMP >
PL701 1-517-630-31 LAMP, PILOT (LCD BACK LIGHT)
PL702 1-517-630-31 LAMP, PILOT (LCD BACK LIGHT)
< TRANSISTOR >
Q710 8-729-421-22 TRANSISTOR UN2211
Q711 8-729-106-60 TRANSISTOR 2SB1115A
Q712 8-729-904-66 TRANSISTOR DTD113EK
Q713 8-729-904-66 TRANSISTOR DTD113EK
Q714 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R701 1-216-045-00 METAL CHIP 680 5% 1/10W
R702 1-216-045-00 METAL CHIP 680 5% 1/10W
R703 1-216-045-00 METAL CHIP 680 5% 1/10W
R704 1-216-049-11 RES,CHIP 1K 5% 1/10W
R705 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R706 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R707 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R708 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R709 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
