– 12 –
HEAT SINK
MAIN BOARD
5
screw
(PTT2.6
×
8)
1
three screws
(PTT2.6
×
8)
2
two screws
(PTT2.6
×
8)
3
three screws
(PTT2.6
×
8)
4
screw
(PTT2.6
×
8)
6
heat sink
4
insulator
3
main boar
d
1
ground point screw
2
two ground point screws
