– 47 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C702 1-136-165-00 FILM 0.1uF 5% 50V
C703 1-136-165-00 FILM 0.1uF 5% 50V
C704 1-136-165-00 FILM 0.1uF 5% 50V
C705 1-136-165-00 FILM 0.1uF 5% 50V
C706 1-136-165-00 FILM 0.1uF 5% 50V
C707 1-136-165-00 FILM 0.1uF 5% 50V
C708 1-136-165-00 FILM 0.1uF 5% 50V
C710 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C711 1-126-933-11 ELECT 100uF 20% 16V
C713 1-136-173-00 FILM 0.47uF 5% 50V
C714 1-126-160-11 ELECT 1uF 20% 50V
C715 1-126-157-11 ELECT 10uF 20% 16V
C717 1-104-665-11 ELECT 100uF 20% 25V
C718 1-124-257-00 ELECT 2.2uF 20% 50V
C731 1-126-157-11 ELECT 10uF 20% 16V
C732 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C741 1-126-157-11 ELECT 10uF 20% 16V
C751 1-126-157-11 ELECT 10uF 20% 16V
C761 1-126-157-11 ELECT 10uF 20% 16V
C901 1-111-233-11 ELECT 5600uF 20% 16V
C902 1-136-165-00 FILM 0.1uF 5% 50V
C911 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C912 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C913 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C914 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C915 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C916 1-124-589-11 ELECT 47uF 20% 16V
C917 1-126-163-11 ELECT 4.7uF 20% 50V
C931 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C932 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C941 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C942 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR/JACK >
CN210 1-766-260-11 CONNECTOR, FFC/FPC (ZIF) 7P
* CN211 1-506-995-11 PIN, CONNECTOR (PC BOARD) 13P
CN571 1-580-907-31 PLUG, CONNECTOR (BUS CONTROL IN)
CN650 1-770-411-11 CONNECTOR, BOARD TO BOARD 20P
CN900 1-774-701-11 PIN, CONNECTOR 16P
CN901 1-774-700-11 JACK, PIN 6P
(BUS AUDIO IN, LINE OUT FRONT/REAR)
< COMPOSITION CIRCUIT BLOCK >
CP10 1-519-504-11 GAP, DISCHARGE
< DIODE >
D9 8-719-976-87 DIODE DTZ3.9A
D10 8-719-040-04 DIODE MA721WK-(TX)
D11 8-719-977-02 DIODE DTZ-TT11-5.6A
D12 8-719-977-25 DIODE DTZ9.1C
D85 8-719-976-87 DIODE DTZ3.9A
D110 8-719-988-62 DIODE 1SS355
D111 8-719-988-62 DIODE 1SS355
D201 8-719-988-62 DIODE 1SS355
D202 8-719-977-25 DIODE DTZ9.1C
D251 8-719-988-62 DIODE 1SS355
D252 8-719-976-87 DIODE DTZ3.9A
D501 8-719-914-44 DIODE DAP202K
D551 8-719-040-04 DIODE MA721WK-(TX)
D552 8-719-988-62 DIODE 1SS355
D553 8-719-105-99 DIODE RD6.2M-B1
D560 8-719-105-99 DIODE RD6.2M-B1
D571 8-719-056-83 DIODE UDZ-TE-17-6.8B
D572 8-719-105-99 DIODE RD6.2M-B1
D573 8-719-105-99 DIODE RD6.2M-B1
D574 8-719-105-99 DIODE RD6.2M-B1
D575 8-719-978-69 DIODE DTZ-TT11-16B
D576 8-719-988-62 DIODE 1SS355
D577 8-719-988-62 DIODE 1SS355
D578 8-719-988-62 DIODE 1SS355
D601 8-719-048-98 DIODE RB160L-40TE25
D602 8-719-048-98 DIODE RB160L-40TE25
D630 8-719-914-43 DIODE DAN202K
D631 8-719-056-83 DIODE UDZ-TE-17-6.8B
D640 8-719-914-43 DIODE DAN202K
D641 8-719-056-84 DIODE UDZ-TE-17-7.5B
D650 8-719-056-88 DIODE UDZ-TE-17-11B
D651 8-719-914-44 DIODE DAP202K
D652 8-719-056-88 DIODE UDZ-TE-17-11B
D661 8-719-105-99 DIODE RD6.2M-B1
D662 8-719-105-99 DIODE RD6.2M-B1
D664 8-719-105-99 DIODE RD6.2M-B1
D667 8-719-105-99 DIODE RD6.2M-B1
D669 8-719-105-99 DIODE RD6.2M-B1
D670 8-719-105-99 DIODE RD6.2M-B1
D671 8-719-056-88 DIODE UDZ-TE-17-11B
D672 8-719-105-99 DIODE RD6.2M-B1
D673 8-719-105-99 DIODE RD6.2M-B1
D680 8-719-988-62 DIODE 1SS355
D682 8-719-105-99 DIODE RD6.2M-B1
D683 8-719-105-99 DIODE RD6.2M-B1
D701 8-719-048-98 DIODE RB160L-40TE25
D702 8-719-048-98 DIODE RB160L-40TE25
D703 8-719-048-98 DIODE RB160L-40TE25
D704 8-719-048-98 DIODE RB160L-40TE25
D705 8-719-048-98 DIODE RB160L-40TE25
D706 8-719-048-98 DIODE RB160L-40TE25
D707 8-719-048-98 DIODE RB160L-40TE25
D708 8-719-048-98 DIODE RB160L-40TE25
D901 8-719-049-38 DIODE 1N5404TU
D905 8-719-988-62 DIODE 1SS355
D906 8-719-048-98 DIODE RB160L-40TE25
D911 8-719-105-99 DIODE RD6.2M-B1
D912 8-719-105-99 DIODE RD6.2M-B1
D915 8-719-988-62 DIODE 1SS355
D916 8-719-976-87 DIODE DTZ3.9A
D917 8-719-976-87 DIODE DTZ3.9A
< IC >
IC10 8-759-448-86 IC TB2114FN(EL)
IC81 8-759-711-82 IC NJM4580E
IC101 8-759-469-16 IC MN1884820Y5F1
IC150 8-759-065-98 IC SAA6579T
IC201 8-759-823-87 IC LB1638M
MAIN
