2SG 310/330 Rev. 2
Operating Instructions
CE Labeling, FCC and Approvals
The SG 310/330 appliances comply with FCC Class A, CE, C-Tick, VCCI and UL.
Important Note: For computer systems to remain CE and FCC compliant, only CE
and FCC compliant parts may be used. Maintaining CE and FCC compliance also
requires proper cable and cabling techniques.
Operating Elements and Connections
SG 310/330 Rev. 2
*
1 x COM
(RJ45)
2 x
USB 3.0
2 x 10 GbE
SFP+ – fixed
8 x GbE copper – fixed.
Incl. 2 bypass pairs
(ports E0/1 and E2/3)
1 x expansion bay
(shown here with optional
FleXi Port module)
Micro USBNavigation
for LCD
Multi-function
LCD display
2 x GbE SFP –
fixed
SG 310/330
1 x
USB 3.0
Power supply
Power switch1 x
HDMI
Connector for optional
PoE Power Module
Connector for optional 2nd
external power supply
* The displayed front image is of SG 330 device. The SG 310 device may vary slightly.
