4SG 430/450 Rev. 2
Operating Instructions
Executable Actions
Ì Change IP Address: This option enables the user to change the interface’s IP
address and netmask. All available and enabled IP addresses can be changed.
Ì Reboot machine: The security appliance is rebooted. The reboot
action will shut down the system completely and reboot.
Ì Shut down: The security appliance is shut down. The shut down action allows
you to turn off the system, and allows you to cleanly stop all running services.
Ì Factory reset: All settings are reset to the factory settings. The factory
reset function sets all of the configuration settings and options to their
original state. All data entered after the initial installation will be deleted,
including the HTTP proxy cache, the entire email queue, accounting
and reporting data, passwords, and uninstalled Up2Date packages.
The version of the software will not change. That is, all firmware
and pattern updates that have been installed will be retained.
Ì Disable OTP (One Time Password) authentication: The OTP
authentication will be disabled for the selected options. This feature
only handles webadmin and shell access options if they are enabled.
Control Key Functions
The current menu is left. When the key is pressed a couple of times, the
modifications are discarded and the initial state will be displayed.
These keys are used to switch between the different menus and/or characters.
Pressing executes the configured action.
Change IP Address
S.NO. Action Item/press What you see on the LCD What it means
1.
Config menu
1. Change IP addr
2.
Interface eth0
192.168.0.1/24
3.
Selects interface
4.
IP address (Eth0)
192.168.0.1
Edit IP address
5.
Changes digit at cursor position
6.
IP address (Eth0)
192.168.0.1
Moves cursor to the
next right position
or
Exits edit mode without saving
7.
eth0 Netmask
24
Displays netmask value after
the last IP address digit
8.
Change netmask value
9. Saves changed IP address
and netmask
