Step 1: Model Series
751 A-F7A-B-A3-N1-CRTT
The 750 Series mechanical level switches are three-stage, displacer-operated switches suitable for
top-insertion tank mounting. Select the sensing unit from the following charts. Then refer to pages
44 - 50 for switching elements, housings and accessories.
Maximum Working Pressure
Step 2: Process Connection Material
751 A -F7A-B-A3-N1-CRTT
Select a process connection material from the chart below. Maximum working pressure in the chart
above is based on the material selected here. Consult the factory for alternative materials.
Displacer units are not available over 450
o
F (232
o
C).
750 Series
Model
Series
Minimum
Specific
Gravity
Function
Connection
Style
Displacer
Material
Connection
Material
Pressure Rating - psig (bar)
100°F (38°C) 450°F (232°C)
750 0.96
Narrow
Differential
NPT
Porcelain All 1000 (69) 750 (52)
751 0.85 SS All 1000 (69) 750 (52)
752 0.96 Flange Porcelain
A105 285 (20) 185 (13)
316SS 275 (19) 182 (13)
753 0.85 Flange SS
A105 285 (20) 185 (13)
316SS 275 (19) 182 (13)
754 0.96
Wide
Differential
NPT
Porcelain All 1000 (69) 750 (52)
755 0.95 SS All 1000 (69) 750 (52)
756 0.96 Flange Porcelain
A105 285 (20) 185 (13)
316SS 275 (20) 182 (13)
757 0.95 Flange SS
A105 285 (20) 185 (13)
316SS 275 (19) 182 (13)
Designator Material
A A105 Carbon Steel fittings or flanges
C A182-TP316/316L Stainless Steel fittings or flanges
*An operating specific gravity is required for all 750 series at time of order.
