Registered Quality System to ISO 9001:2008
9/60
Form 912
sorinc.com
913-888-2630
101 A-A1C-B-A1-N4-CRTT
The 100 Series mechanical liquid level switch is float operated with a flanged, serviceable external
chamber. Select the sensing unit from the following charts. Then refer to pages 44 through 50 for
switching elements, housings and accessories.
Select a model series from the charts below based on maximum operating pressure and minimum
specific gravity.
Maximum Working Pressure
See page 53 for pressure ratings at higher temperatures.
Minimum Specific Gravity
For Monel Trim please consult factory.
Step 1: Model Series
*Consult the factory for pressure ratings of units with Monel trim.
100 Series
Model
Series
Minimum Specific Gravity
(Dual Switch, anti-vibration, pneumatic or extra-high temperature)
Standard w/ ET or FE Option
316SS / 400SS
“B” Trim
All 316SS
“C” Trim
316SS / 400SS
“B” Trim
All 316SS
“C” Trim
101
102
103
0.52
0.62
0.51
(0.64)
(0.73)
(0.57)
0.56
0.66
0.53
(0.67)
(0.77)
(0.59)
0.56
0.65
0.53
(0.67)
(0.76)
(0.59)
0.60
0.69
0.55
(0.71)
(0.80)
(0.61)
104
109
121
0.62
0.38
0.66
(0.68)
(0.41)
(0.87)
0.64
0.39
0.73
(0.70)
(0.42)
(0.94)
0.64
0.39
0.72
(0.70)
(0.42)
(0.93)
0.66
0.40
0.79
(0.72)
(0.43)
(1.01)
122
123
124
0.66
0.93
0.94
(0.87)
-
-
0.73
0.98
0.99
(0.94)
-
-
0.72
0.99
1.00
(0.94)
-
-
0.79
1.04
1.05
(1.01)
-
-
Model
Series
Chamber
Material
Pressure at Listed Temperature in psid (bar)*
100°F (38°C) 200°F (93°C) 300°F
(149°C)
350°F (177°C) 400°F (204°C) 450°F (232°C)
101
A106B
316SS
285
275
(19.7)
(18.9)
260
235
(17.9)
(16.2)
230
215
(15.9)
(14.8)
215
205
(14.8)
(14.1)
200
195
(13.8)
(13.4)
185
182
(12.8)
(12.6)
102
A106B
316SS
500
500
(34.5)
(34.5)
500
500
(34.5)
(34.5)
500
500
(34.5)
(34.5)
486
486
(33.5)
(33.5)
473
473
(32.6)
(32.6)
460
460
(31.7)
(31.7)
103
A106B
316SS
740
720
(51.0)
(49.7)
675
620
(46.6)
(42.8)
655
560
(45.2)
(38.6)
645
537
(44.5)
(37.0)
635
515
(43.8)
(35.5)
622
497
(42.9)
(34.3)
104
A106B
316SS
990
1000
(68.2)
(69.0)
900
1000
(62.0)
(69.0)
875
1000
(60.3)
(69.0)
860
973
(59.2)
(67.1)
845
946
(58.2)
(65.2)
822
920
(56.6)
(63.4)
109
A106B
316SS
285
275
(19.7)
(18.9)
260
235
(17.9)
(16.2)
230
215
(15.9)
(14.8)
215
205
(14.8)
(14.1)
200
195
(13.8)
(13.4)
185
182
(12.8)
(12.6)
121
A106B
316SS
285
275
(19.7)
(18.9)
260
235
(17.9)
(16.2)
230
215
(15.9)
(14.8)
215
205
(14.8)
(14.1)
200
195
(13.8)
(13.4)
185
182
(12.8)
(12.6)
122
A106B
316SS
350
350
(24.1)
(24.1)
350
350
(24.1)
(24.1)
350
350
(24.1)
(24.1)
340
340
(23.4)
(23.4)
331
331
(22.8)
(22.8)
322
322
(22.2)
(22.2)
123
A106B
316SS
740
720
(51.0)
(49.7)
675
620
(46.6)
(42.8)
655
560
(45.2)
(38.6)
645
537
(44.5)
(37.0)
635
515
(43.8)
(35.5)
622
497
(42.9)
(34.3)
124
A106B
316SS
1250
1250
(86.2)
(86.2)
1250
1250
(86.2)
(86.2)
1250
1120
(86.2)
(77.2)
1216
1075
(83.9)
(74.1)
1182
1030
(81.5)
(71.0)
1150
992
(79.3)
(68.2)
