6
Description of controller
B.1. - Specifi cations
°C0 102030405060708090100
1000 1039 1077 1116 1155 1194 1232 1270 1308 1347 1385
Mains voltage 230 AC +/- 10%
Mains frequency 50 - 60Hz
Power consumption ~ 1.5VA
Internal fuse 2A slow blow 250V
Protection category IP40
Protection class II
Overvoltage Category II
Degree of Pollution Category II
Vers.1 Vers.2 Vers.3 Vers.4
mechanical relay 460VA for AC1 / 460W for AC3 1-1-
electronic relay min.5W...max.120W for AC3 -1-1
0-10V output, tolerance 10%, 10 k load or
PWM output freq. 1 kHz, level 10 V
--11
PT1000 sensor input measuring range -40°C to 300°C3333
Permissible cable length of sensors and appliances:
sensor S1 (e.g. collector sensor) <30m
sensors S2 and S3 (e.g. storage sensor) <10m
PWM / 0...10V <3m
electronic relay <3m
mechanichal relay <10m
Permissible ambient conditions:
Ambient temperature
- for controller operation 0°C...40°C
- for transport/storage 0°C...60°C
Air humidity
- for controller operation max. 85% rel. humidity at 25°C
- for transport/storage no moisture condensation permitted
Other specifi cations and dimensions
Housing design 2-part, ABS plastic
Installation methods Wall installation
Overall dimensions 115mm x 86mm x 45mm
Aperture installation
dimensions 108mm x 82mm x 25.2mm
Display Fully graphical display, 128 x 64 dots
Operation 4 entry keys
B.2. - Temperature resistance table for Pt1000 sensors
