16, 22, 22MTK User Manual
1.3: SPECIFICATIONS
INTRODUCTION > SPECIFICATIONS
1.3: INTRODUCTION > SPECIFICATIONS
TYPICAL SPECIFICATIONS
• Frequency Response
- Mic / Line In to any Output: +/-1.5dB, 20Hz-20kHz
• T.H.D.
- Mono Mic Sensitivity -30dBu, Input level -16dBu,
+14dBu @ Mix output: < 0.002% @ 1kHz
- Stereo Mic Sensitivity -30dBu, Input level -16dBu,
+14dBu @ Mix output: < 0.007% @ 1kHz
• Noise
- Mono Mic Input E.I.N. (max gain): <-124dBu
(150Ωsource)
- Stereo Mic Input E.I.N. (max gain): <-124dBu
(150Ωsource)
• Crosstalk (@ 1kHz)
- Channel Mute: >-90dB
- Fader Cut-off (rel +10 mark): >-90dB
- Aux Send Pots Offness: >-82dB
EQ (Mono inputs)
- HF: 12kHz, +/-15dB
- HMF (swept): 400Hz – 8kHz, +/-15dB
- LMF (swept): 80Hz – 2kHz, +/-15dB
- LF: .60Hz, +/-15dB
EQ (Stereo inputs)
- HF: 12kHz, +/-15dB
- MF (swept): 140Hz - 3kHz, +/-15dB
- LF: 60Hz, +/-15dB
Power Consumption
- Signature 16: <80VA
- Signature 22: <100VA
- Signature 22MTK: <120VA
Operating Conditions
- Temperature Range: 5°C to 40°C
Input & Output Levels
- Mic Input: +12.5dBu max
- Line Input: >+26dBu max
- Stereo Inputs: >+26dBu max
- Mix Output: +21.5dBu max
-Headphones(@150Ω):300mW
Input & Output Impedances
-MicInput:1.2kΩ
-Hi-ZInput:968kΩ
-LineInput:10kΩ
-StereoInput:21.5kΩ
-Outputs:150Ω(balanced),75Ω(unbalanced)
USB Audio (16, 22)
- Inputs/Outputs: 2-in, 2-out
- Bit Depth: 16-bit, 24-bit
- Sampling rate: 44.1kHz / 48kHz / 88.2kHz / 96kHz /
176.4kHz / 192kHz
Multi-channel USB Audio (22MTK)
- Inputs/Outputs: 24-in, 22-out
- Bit Depth: 16-bit, 24-bit
- Sampling rate: 44.1kHz / 48kHz
Net Weight
- Signature 16: 8.66kg
- Signature 22: 11.06kg
- Signature 22MTK: 11.36kg
Unit Dimensions (W × H × D)
- Signature 16: 630mm x 595mm x 210mm
- Signature 22: 750mm x 630mm x 210mm
- Signature 22MTK: 750mm x 630mm x 210mm
