SoundCraft Signature 22 User Manual

16, 22, 22MTK User Manual
3.0: INPUTS AND OUTPUTS
INPUTS AND OUTPUTS
3.0: INPUTS AND OUTPUTS
The physical inputs and outputs on the Signature console are varied, and together with the Ghost mic
preamps,dbx®limiting,andHi-Zinputsprovideaexibleschemeforanysourcesyoumight
encounter. To get the most out of the Signature I/O, read this chapter carefully.

SoundCraft Signature 22 Specifications

General

Channels	22
Faders	100mm
Type	Analog Mixer
Inputs - Mic Preamps	16 x XLR
Computer Connectivity	USB
Phantom Power	Yes
Subgroups	4
Mic Preamps	16
EQ Bands	3-band
Effects	Lexicon Effects Engine
Inputs - Line	22 x 1/4"
Inputs - Other	2 x RCA (Stereo)
Outputs - Main	2 x XLR
Outputs - Other	1 x 1/4" (Headphones)
Aux Sends	5 Aux Sends
