16, 22, 22MTK User Manual
7.0: USB OPERATION
USB OPERATION
7.0: USB OPERATION
The Soundcraft Signature consoles use USB 2.0 audio streaming for sending and receiving digital
audio. The Signature 16 and 22 consoles have a two-track USB system while the Signature 22MTK
(Multi-Track) uses a 22-channel system for channel direct inputs and outputs, plus a two-channel sys-
tem for the Playback Channel and recording the recording the main LR mix.

SoundCraft Signature 22 Specifications

General

Channels	22
Faders	100mm
Type	Analog Mixer
Inputs - Mic Preamps	16 x XLR
Computer Connectivity	USB
Phantom Power	Yes
Subgroups	4
Mic Preamps	16
EQ Bands	3-band
Effects	Lexicon Effects Engine
Inputs - Line	22 x 1/4"
Inputs - Other	2 x RCA (Stereo)
Outputs - Main	2 x XLR
Outputs - Other	1 x 1/4" (Headphones)
Aux Sends	5 Aux Sends
