SoundCraft Signature 22 User Manual

16, 22, 22MTK User Manual
5.0: CHANNEL CONTROLS
CHANNEL CONTROLS
5.0: CHANNEL CONTROL
There are three types of Signature console input channels: Mono Input, Stereo Input, and FX Return.
The output channel types are the Auxiliary (Aux) Master Outputs, the Master Stereo Outputs, and the
Group (GRP) Master Outputs.

SoundCraft Signature 22 Specifications

General

Channels	22
Faders	100mm
Type	Analog Mixer
Inputs - Mic Preamps	16 x XLR
Computer Connectivity	USB
Phantom Power	Yes
Subgroups	4
Mic Preamps	16
EQ Bands	3-band
Effects	Lexicon Effects Engine
Inputs - Line	22 x 1/4"
Inputs - Other	2 x RCA (Stereo)
Outputs - Main	2 x XLR
Outputs - Other	1 x 1/4" (Headphones)
Aux Sends	5 Aux Sends
