Soundstream VRCPAA-70M User Manual

will show the languages setting
During initial power on, the unit
interface, select the required
country and language, then press
“√” to enter the main menu.
Radio: Shows the Radio interface.
Phone
Android Auto/CarPlay:
: Shows the Bluetooth
connection interface.
Shows the relevant interface based
on your connected device.
USB: Shows the USB playback
interface for compatible files.
BTMusic: Shows the music playback
interface.
Card : Shows the TF Card interface,
enabling playback for
compatible files.
FUNCTIONS APPLICATION
Basic Operations
Main Menu
Please refer to the actual menu
display for reference.
Radio
Touch “Radio” in the main menu to
enter the radio interface.
【
】
To return to the main menu.
【
】
Switch between FM1/FM2/FM3
/AM1/AM2.
【
】
Enter the EQ settings interface.
【
】
Turns the LOC function on/off.
Seting : Shows the Settings interface.
F-camera: Turn on the front camera.
AV-In : Shows the AUX interface.
Screen off: Turns off the screen, to
reactivate the screen
simply press any part of
the screen.
4
【 】
Shows the Radio tuning
input interface, input the
frequency directly or selected
preset stations to start playing.
Scans for available stations,
long press to automatically search
and save stations with the strongest
signals into the presets.
【
】

Soundstream VRCPAA-70M Specifications

Power

power supply	DC10-16V
current drain	15A
grounding system	Negative Ground

Operating Environment

operating temperature	-20~+60℃

Display

tft screen size	7 inch
resolution	800x480 Pixels

FM Radio

frequency range (usa)	87.5~107.9MHz
frequency range (europe)	87.5~108.0MHz
enable sensitivity (s/n=30db)	≤15dB

AM Radio

frequency range (usa)	530~1710KHz
frequency range (europe)	522~1620KHz
enable sensitivity (s/n=20db)	≤40dB

Weight and Dimensions

dimensions	178mm(W)x168mm(D)x100mm(H)
