Soundstream VRCPAA-70M User Manual

FUNCTIONS APPLICATION
6
Touch to delete numbers one
by one, long press to delete all
inputted numbers.
Touch
to show the numbers
keyboard, touch again to exit.
Touch
to hang up the call.
Touch
to switch call audio
to earphone/AV receiver.
Touch
to mute.
Note: You can also manage
calls through your phone.
Calling Record
Check for dialed/answered/
missed calls history. Touch
icon to enter calling record
interface:
: Delete dialed calls.
Phone Book
:Delete Contacts.
External Play Device
:
1 2 3 4 5 6 7
8 9
When your phone and unit are
paired, the unit can automatically
reach contacts from your phone
and store them within the unit.
(selected phones only)
When you connect a compatible
data device to your unit, the
following interface will appear.
VRCPAA-70M
VRCPAA-70M
USB
USB
GOTO

Soundstream VRCPAA-70M Specifications

Power

power supply	DC10-16V
current drain	15A
grounding system	Negative Ground

Operating Environment

operating temperature	-20~+60℃

Display

tft screen size	7 inch
resolution	800x480 Pixels

FM Radio

frequency range (usa)	87.5~107.9MHz
frequency range (europe)	87.5~108.0MHz
enable sensitivity (s/n=30db)	≤15dB

AM Radio

frequency range (usa)	530~1710KHz
frequency range (europe)	522~1620KHz
enable sensitivity (s/n=20db)	≤40dB

Weight and Dimensions

dimensions	178mm(W)x168mm(D)x100mm(H)
