Source 1 S1-THSU302-S - Technical Specifications

Technical Specifications
S1-THSU302-S Thermostat Controllers
Power Requirements
20 - 30 VAC 50/60 Hz, 3.0 VA @ 24V nominal.
W1, W2, W3 = 0.2A max, 0.01A min, 3A inrush, 20 - 30 VAC
Y1, Y2, G = 0.4A max, 0.01A min, 3A inrush, 20 - 30 VAC
Thermistor, NTC 10K @ 25˚C
Thermistor, NTC 10K @ 25˚C
16 AWG (100 ft max) to 24 AWG (36 ft max)
35˚ to 99˚ deg F (2˚ to 36˚ deg C)
35˚ to 65˚ deg F +/- 3˚ degF, greater than 65˚ to less than 80 degF +/- 2 degF,
80˚ to 99˚ deg F +/- 3˚ degF, greater than 99˚ to 104˚ deg F +/- 5˚ deg F
Adjustable 1˚ to 6˚ deg first stage, 0˚ - 10˚ deg 2nd & 3rd stages
35˚ to 104˚ deg F (2˚ to 40˚ deg C), 5 - 95% RH non-condensing, 86˚ deg F
max dew point
-22˚ to 122˚ deg F (-30˚ to 50˚ deg C), 5-95% RH non-condensing, 86˚ deg F
max dew point
UL/cUL listed, file E468676, NEC Class 2
4.4” H x 5.2” W x 1.0”D
0.34 kg
Output Rating
Local Temperature
Sensor Type
Remote Temperature
Sensor Type
Temperature Adjustment
Range
Accuracy
Wire Size
Deadband
Operating
Storage
Ambient
Conditions
Compliance
Dimensions
Shipping Weight
