South-Tek Systems N2-BLAST FPS-500 User Manual

Version: 1
Revision Date: 02/2018
N
2-BLAST
®
FPS-500
O&M Manual
Page: 10 of 25
Contact us Toll-Free: (888) 526-6284
SITE AND UTILITY REQUIREMENTS
4.1 AIR SUPPLY
The N2-BLAST
®
FPS-500 includes a built-in air compressor to supply gas to the nitrogen generator.
It is not for performing quick lls. Please install a separate suitable air compressor for other needs .
4.2 ADDITIONAL PIPING AND HOSINGS
Sourcing and installing additional plumbing, supplied by other manufacturers, must meet all of
the unit’s flow, pressure, and temperature requirements. If piping length between any equipment
is greater than 50 feet, consult with a piping contractor for proper line size.
4.3 ELECTRICAL REQUIREMENTS
The N
2-BLAST
®
FPS-500 requires 120VAC / 50-60hz / 1ph and draws < 8A. A 240VAC option
is also available. It has a built-in 20A over-current protection device and comes with a standard
3-prong US power cord for the electrical connection (unless otherwise specied). It comes with
UL 508A ICP certication, and the electrical schematics are available upon request.
4.4 SITE SPECIFICATIONS
Unless designed otherwise, install in a nonhazardous indoor location with temperatures between
40-100°F (4°- 38°C). For ease of maintenance, troubleshooting, and minimizing pressure drop,
install the equipment in the same area. Leave enough space around the generator and other
equipment for routine maintenance.
4
