Southwire 14090T User Manual

19
Specifications cont.
600.0µA
6000µA
60.00mA
600.0mA
10.00A
All AC current ranges are specified from 5% to 100% of range.
Overload Protection: µA, mA ranges: 800mA/1000V Fuse
10A range: 10A/1000V Fuse
AC current bandwidth: 50 to 400Hz
0.1µA
1µA
10µA
0.1mA
10mA
±(1.0% +3 digits)
±(2.0% +8 digits)
AC Current
Function Range Resolution Accuracy ± (% of reading + digits)
9.999Hz
99.99Hz
999.9Hz
9.999kHz
Input Protection: 600V AC RMS or 600V DC
Sensitivity: >8V RMS
0.001Hz
0.01Hz
0.1Hz
1Hz
±(1.0% +5 digits)
Frequency
Function Range Resolution Accuracy ± (% of reading + digits)
6.000V
60.00V
600.0V
1000V
All AC + DC voltage ranges are specified from 5% to 100% of range.
Input Protection: 1000V AC RMS or 1000V DC
Input Impedance: 10M
AC voltage bandwidth: 50 to 400Hz
1mV
10mV
0.1V
1V
±(2.0% + 30 digits)
±(2.0% + 5 digits)
AC+DC Voltage
Function Range Resolution Accuracy ± (% of reading + digits)
20.0% to 80.0%
Input Protection: 600V AC RMS or 600V DC
Pulse Width: 0.1 to 100mS
Frequency Range: 5Hz to 10kHz
Sensitivity: >8V RMS
0.1% ±(1.2% +2 digits)
Duty Cycle
Function Range Resolution Accuracy ± (% of reading + digits)
20
Specifications cont.
60.00nF
600.0nF
6.000µF
60.00µF
600.0µF
6000µF
Input Protection: 600V AC RMS or 600V DC
*Accuracy is not stated below 6nF
10pF
100pF
0.001µF
0.01µF
0.1µF
1µF
±(5.0% +35 digits)*
±(3.0% +5 digits)
±(5.0% +5 digits)
Capacitance
Function Range Resolution Accuracy ± (% of reading + digits)
-4°F to 1400°F
-20°C to 760°C
Input Protection: 600V AC RMS or 600V DC
0.1°F
0.1°C
±(1.5% +9ºF)
±(1.5% +5ºC)
Temperature
Function Range Resolution Accuracy ± (% of reading + digits)
600.0Ω
6.000kΩ
60.00kΩ
600.0kΩ
6.000MΩ
60.00MΩ
Input Protection: 600V AC RMS or 600V DC
0.1Ω
1Ω
10Ω
100Ω
1kΩ
10kΩ
±(1.5% +5 digits)
±(2.0% +10 digits)
Resistance
Function Range Resolution Accuracy ± (% of reading + digits)
600.0µA
6000µA
60.00mA
600.0mA
10.00A
Overload Protection: µA, mA ranges: 800mA/1000V Fuse
10A range: 10A/1000V Fuse
0.1µA
1µA
10µA
0.1mA
10mA
±(1.0% +3 digits)
±(1.5% +3 digits)
DC Current
Function Range Resolution Accuracy ± (% of reading + digits)

Southwire 14090T Specifications

General

Brand	Southwire
Model	14090T
Category	Measuring Instruments
Language	English
