Sovol SV01 - Cable Connection Guide; Printer Wiring Instructions

X
EXP1
EXP2
Z
E
4-WIRE CONNECTORS
X Y Z
2-WIRE CONNECTORS
ZZ EYX
FD
Y
Z
Z
Y
X
Make connections
The cables are provided with
labels, observe them and the type
of connector for proper
identication.
Make the connections being
careful not to bend the connector
pins.
The display board has three
identied inputs. Connect the
Exp1 and Exp2 cables in their
corresponding place leaving the
Exp3 input empty..
Cable Connection
08
IMPORTANT
Do not forget to place the voltage selector in the position
corresponding to your local mains (220V or 110V).
Use a grounded electrical outlet.
