3
3
Install the lament spool holder.
Secured in the screw hole of the
lament holder with M4x8 (2)
and M4 T-Nut (2). Loosen the
T-nuts by hand and turn them so
they will t inside the grooves on
the frames.
You want the nuts to be loose so
that when you tighten the bolts,
the nut will rotate 90° and grab
onto the inside of the groove.
Tighten with an Hex key (Allen).
Assembly - Step 3
05
M4x8 + T-NUTS (2 Units)
2.4mm
