Soyal AR-725-E - Page 10

V220916
- 10 -
Illuminated Touch-panel
Access controller
Command List
Function Command Exposition
Lift control setting: multi-doors 21 UUUUU G LLLLLLLL
UUUUU
＝user address；
G=4 sets of lift control(0~3);
LLLLLLLL=8 assigned oor (F=0: Disable, 1: Enable)
Add/Delete tag by presenting (M6 only) 22 N N=0(Delete tag); N=1(Add tag)
AR-401RO16/ AR-401RO16B relay time setting 23 MMM TTT
MMM=Node ID of lift controller
TTT= relay time: 000~600=1~600 sec.
Factory setting 24 0 or 1 ???
0 or 1＝Enable target unit (0=
Main Controller Parameter
Setting
, 1=WG Input Port Parameter Setting)
???
：
Function default value
Real time clock setting 25 YYMMDDHHMMSS YYMMDDHHmmSS: Year/Month/Day/Hour/Min./Sec.
Anti-pass-back (Enable user) 26 SSSSS EEEEE P
SSSSS= starting user address; EEEEE= ending user address
P=0=Enable; P=1=Disable; P=2=Initial
Lift control setting: single door 27 UUUUU LL
UUUUU＝user address；LL：Floor number(01~64 oor)
Duress Function and Arming output setting 28 FFF
Arming output and Duress function: FFF= 008 (default value)
Delete all tag 29 29
Same tag reading interval time 31 TTTT
Base on 10ms, range from 10 to 6000
Auto ring the clock alarm schedule 32 SS HHMMTT 7123456H
SS= 16 sets auto alarm schedule, range 0~15
HHMM= HH:MM (ex. 0830: Ring bell at 08:30)
TT=Period of time to ring bell
(Base on second, range 01~99 sec.)
7123456: 7 days of week -Sun/Mon/Tue/Wed/Thu/Fri/Sat
(Input value: 0=disable; 1=enable)
H: Holiday (Input value: 0=disable; 1=enable)
Holiday Setting 35 MMDD F
MM= Month of year (01=Jan...10=Oct.)
DD= Date of month (01=1st day of month)
F= 0:Delete ; 1: Add
Enabling or Disabling into Full Access status 36 MW
M=
AR-725-E
; W=WG Reader (0=disable; 1=enable)
RS485 port function setting
(Needs to be restarted after setting)
37 AB
A＝0:AR401RO B＝0: 9600(default value)
1:Host (default value) 1: 19200
2:LED Panel 2: 38400
3:Printer
3: 57600
TTL port BAUD setting 38 DDD
DDD : 001＝4800 bps DDD : 065＝9600 bps
DDD : 129＝19200 bps
Change WG bits output format 41 n
n：0＝WG26 ； n：1＝WG34
PIN & UID Length setting
42 m n
m＝PIN code Length 4~8 Digit / n＝ UID Length 2~8 Digit
Compound Command Function List
20 0 ??? (Main Controller Parameter Setting)
20
1 ??? (WG Input Port Parameter Setting)
※
Default Value
Function Option Value
Bit
Application
Entry and Exit Access is recorded on Duty Report
※
0: Yes 1: No 001 0 Networking
Activate close door automatically lock (Auto-Relock)
※
0: Disable 1: Enable 002 1 Networking/Stand-Alone
Auto Open
※
0: Disable 1: Enable 004 2 Networking/Stand-Alone
When Access Mode is "Card and PIN", Readers can skip pressing PIN code
※
0: Disable 1: Enable 008 3 Networking/Stand-Alone
Exit by Push Button 0: Disable
※
1: Enable 016 4 Networking/Stand-Alone
Enable force Open trigger alarm
※
0: Disable 1: Enable 032 5 Networking
Entry/Exit Reader
※
0: Exit 1: Entry 064 6 Networking
Anti-pass-back
※
0: Disable 1: Enable 128 7 Networking
Weighted Value Manual :
"Selection" of the function that you need is either
have 0 or 1 value.
Substract the "Value" of each Option with Selection.
Function = [0(deactive)*Value] ; [1(activate)*Value]
Add up all of the Function per Compound Command
(20 , 24 ,etc)
Step 1:
Select the "Function" that you need for each
Compound Command category (20 , 24 , etc)
Step 2:
Step 3: Step 4:
