Soyal AR-725-E - Current State; Networking Setting; User Password

V220916
- 8 -
Illuminated Touch-panel
Access controller
IP Setting
Log-in User Password
When you choose the "Networking Setting" or "User Password" at rst.
Log-in window will pop out and please input
※
At the Factory Default
User name: SuperAdm
Password: 721568
Open your Web Browser and input factory default IP
address: http://192.168.1.127
Networking Setting
You will nd initial IP Address 192.168.1.127 and check
MAC Address is the same as sticker on Ethernet Module
device. Please revise IP address you want, and then click
“Update” button. After updating the IP, please re-connect
the Web Browser by new IP address.
User Password
The password composes of 10 characters at most, it can be
either A~Z or 0~9.
Change the log-in password to lock the IP setting of
Ethernet Module.
If the IP address of AR-725-E has
changed We must enter the new
IP address.
Page menu
Current State
Online Status is able to monitor and show which computer is linking on
Ethernet Module
IP Setting
Monitor the on-line computer
Change the Log-in information
IP Setting
Show which computer is linking
on Ethernet Module.
Current IP address of the AR-725-E
Page menu
User Name is different from old and new version, password can be modify via [User Password]
setting on the list but will not be change from updating new version. If you forgot the password,
the solution is pressing Reset Button to reset it as default value.
NOTE :
Firmware Version User name Password (changeable)
After 2020/01/21 SuperAdm Default Password : 721568 or self-denition
Before 2020/01/21 admin Default Password : admin/ password not required or self-denition
