Spa-Quip SP400P User Manual

HEATHEAT PUMP AUTO AIR PUMP AUTO AIR
ONON
AUTO
PUMP
HEATER
AIR
ON
<TEMP SET>
HOLD BUTTON
TO ADJUST
PRESS BOTH
TO READ ACTUAL
The green Pump indicator light will appear on the touch pad whenever the pump is running, in both
auto and manual use mode. If this light is flashing, the spa is in Sleep Mode.
Pump LED
The red Heater indicator light will appear on the touchpad whenever the heater element is on, in
both auto and manual use mode. For safety the heater is always automatically controlled.
Usually switching on the air blower accessory will cause the heater to switch off (loadshedding).
This is in order to keep the total power load to a safe level. If this light is flashing the system has an
error
Heat LED
(see section8).
H20 LED (24hr circulation pump fitted)
The yellow H20 light indicates if water is present in the heater. If no water is detected then the LED
will flash and the unit will not operate except to run the circulation pump to try to get water to the
heater. If no water reaches the heater for one minute then an H20 error will occur. If this happens
then pushing the pump button will run the circulation pump for another minute.
Page 1
Congratulations on choosing the latest Spa Power control system. This
controller makes use of the latest technology, including innovative optical and
digital sensor designs. The greater variety of optional accessories, user-
friendly touchpad and reliable components provide you with the most
sophisticated controller in its class.
Heat LED
Pump LED
Auto/H20 LED
Aux/Air LED
Aux/Air/Pump Button
Up Button
Down Button
Heat LED
Pump LED
Auto/H20 LED
Aux/Air LED
Pump Button
Pump Button
Aux/Air/Pump Button
Up Button
Down Button
37.0
1 Touch Pads
Auto LED (No 24hr circulation pump fitted)
The yellow Auto indicator light will appear on the touch pad whenever the system is in full
automatic control mode. In this mode the system automatically activates the pump and heater to
filter the water and maintain the set water temperature. If this light is flashing the water sensor is
not detecting any water.
Aux/Air LED
The Aux/Air indicator LED will appear on the touchpad whenever the Aux/Air button is pushed
and conversly will disapear when the button is pushed again. Note: If the spa does not have a
load connected to the controller the LED will still operate as described above.
37.0

Spa-Quip SP400P Specifications

General

Brand	Spa-Quip
Model	SP400P
Category	Controller
Language	English
