1. Verify the power switch is turned to OFF.
2. Remove the torque arm, rst pulling up out of
the torque assembly and then down out of the
at sensor arm.
3. Remove dispensing door hand-screws (4).
4. Remove dispensing door assembly, torque
assembly, and beater assembly.
5. Remove torque assembly O-ring using O-ring
tool; remove torque guide.
6. Remove scraper blades from beater assembly
7. Remove dispensing door gasket using O-ring
tool.
8. Rotate draw valve unl the at part at the top is
perpendicular to the clear face of the dispensing
door (use towel if necessary).
9. Remove ice buster.
10. Remove draw valve, twisng it while removing.
11. Remove draw valve O-rings (2) using O-ring tool.
12. Unscrew and remove prime plug from
dispensing door.
13. Use a towel to remove drive sha at the back of
the cylinder.
14. Separate drive sha gasket from drive sha.
15. Remove front drip tray and internal drip tray.
Prepare dishwashing area prior to
disassembly, and use a bucket to temporarily store
removed parts.
Always separate O-rings and gaskets from
metal parts to prevent damage while washing.
