Assemble the Base
12
A
ASSEMBLE THE OVAL POLE
CAUTION
IF MINIMUM POLE ENGAGEMENT OVERLAP OF 9 CM (3.5 in) CANNOT BE ACHIEVED !! STOP !! DO
NOT PROCEED TO THE NEXT STEP! - CALL SPALDING CUSTOMER SERVICE AT 1-800-558-5234 FOR
ASSISTANCE.
3. Align the top (4) pole section with the middle (5) pole section and slide together.
4. Bounce assembled sections on a scrap wood board until the overlap reaches the marked line.
#5
#5
#5
#4
#4
#4
3-1/2"
(9 cm)
9 cm
(3.5 in)
5. Align the assembled oval pole section with the bottom (6) pole section and slide together.
6. Bounce assembled sections on a scrap wood board until the overlap reaches the marked line.
#5
#6
#4
#5
#6
3-1/2"
(9 cm)
9 cm
(3.5 in)
To Next Page
