Promise to Perform Industries, Inc.
A-SERIES ALUMINUM GANTRY CRANE MANUAL
2 Spanco
®
A-Series Aluminum Gantry Crane
• 1-800-869-2080 • Spanco.com
ASSEMBLY INSTRUCTIONS
1. Equipment Needed for Assembly
a ) This manual
b ) Applicable safety equipment for workers’ use during assembly, such as hard hats, safety shoes, etc.
c ) Measuring tape
d ) Torque wrench
e ) Long carpenter’s level or laser level
f ) Wrench/socket sets up to 7/8 inches.
g ) A spacious, level area for assembly (e.g., parking lot)
h ) A way to mark locations, such as a permanent marker
i )
A-SERIES-ALU-ASSEMBLY SHEET 1 OF 2,
hereafter referred to as
A-Series Aluminum Gantry Crane Assembly
Drawing
, included as a separate document.
j )
A-SERIES-ALU-ASSEMBLY SHEET 2 OF 2,
hereafter referred to as
A-Series Aluminum Gantry Crane Label Placement
Drawing
, included as a separate document.
2. Inventory
a ) Open all bundles and confirm that all components are accounted for: see
Building Materials Description
located
in the top right corner of the A-Series Aluminum Gantry Crane Assembly Drawing. Note that the quantity of
components in an assembly are multiplied by the number of the assemblies.
b ) Check for damage to components that may have occurred during shipping.
c ) Your A-Series Gantry Crane consists of the following components:
1 ) One Beam
2 ) One Beam Hardware Kit
3 ) Two A-Frame Assemblies
4 ) Two Upright Tubes
5 ) Two Top Plate Assemblies
6 ) Four Casters
7 ) One Caster Mounting Hardware Kit
NOTE: Your system may also include optional accessories, such as a Height Adjustment Kit, extension tubes, wheel
brakes, and other optional components.
NOTE: One half-and one-ton models are manufactured with with square edge tubing. Two- and three-ton models
are manufactured with rounded edge aluminum tubing.
Two- and three-ton model
tubing profile.
One half- and one-ton model
tubing profile.
