10
MOUNTING THE MAIN A LARM MODULE
Locate a mounting p o sition for th e alarm in the vehicle engine compartment close to
the front of the vehicle and in a position where it is difficult to again access to the
alarm wiring from below the car.
Ensure that the alarm is located away from extreme heat, areas subject to water and
at least 12” from the ignition system. (Use silicone sealant enclosed whe n refitting
boot).
Using the alarm bracket as template, drill 2 holes and secure the bracket to the car
body-work using the self tapping screws provided, making sure the alarm bracket is
solidly mounted.
Check behind any panels for hidden pipes or wiring before
drilling holes.
Secure the alarm to the bracket using the small bolts supplied m aking
sure that front face of the alarm is kept vertical to ensure effective operation of the
shock sensor.
HARNESS LOCATION
Position the harness to the rear of the main alarm module and secure where
necessary to the vehicle wiring using insulation tape.
Plug in the main harness connector to the rear of the alarm unit .
Do not fit the rubber boot to the alarm at this stage.
You c an now make connections to the car wiring as shown.
All wires
MUST be connected in the sequence outlin ed in these instructions.
