8
FITTING INSTRUCTIONS
IMPORTANT:
• Your SRA8 is suitable for 12V negative earth vehicles only.
• Refer to Car Owners m anu al for the procedure for disconnection of your
battery
before commencing the installation of this Alarm.
• The vehicle battery must be disconnected during the installation procedure
except where it is necessar y to carry out circuit testing specified.
• Vehicles fitted with digital radios having a security code or memory feature will
require re-programming on completion of the installation.
• Ensure you have noted the security code of your radio to disconnecting the
vehicle battery.
• It is suggested that the alarm is tested before the ultrasonic unit has been
fitted.
VEHICLE WIRING TESTING
If you are unable to easily identify the correct wire on the vehicle to make a connection it is
recommended a 12 volt test lamp or mu lti-met er is used. Care must be taken to ensure that the
wire being tested is not accidentally shorted to earth by the test lamp or multi-meter probes.
INSTALLATION NOTES
The wiring harness is fully assembled and supplied with in-line fuses on the RED wire
(10 amp), VIOLET (5 amp) and GREY (5 amp) wires, if any fuse blows, it is e ssentia l
to investigate the cause and then replace with a fuse of the correct rating. Spare fuses
are readily available from automotive accessory sto res. W hen routing the harness
around the engine compartment and through a bulkhead inside the vehicle en sure the
wires insulation cannot be damaged in sharp metal edges. The harness sho uld be
concealed and protected wherever possible by using g ood qua lity insulatio n tape.
It is recommended that wherever possible connection to the vehicle wiring is carried
out at the steering colum n or at the fuse box. This will prevent tampering of the wirin g
from outside of the vehicle.
