The BLUE wire can then be connected to the door switch
wire using a solder joint, crimp termination or an IDC
connector.
If the courtesy light remains on w hen the door switch is
removed, contact Sparkrite for installation details specific to
your car.
IMPORTANT: The Passive Arming function will only
work if the BLUE wire is connected as described above
BLACK WIRE-EARTH
The BLACK wire must be connected to a good clean metal
earthing point on the body-work of the vehicle. Drill a
suitable hole nea r the main alarm unit and secure the
BLACK wire through the ring terminal.
NOTE: Do not mount the BLACK earth wire on the alarm
bracket as the anti-corrosion paint will prevent a good earth
contact. If in any doubt the BLACK earth wire can be
connected directly to the battery negative terminal
ORANGE/WHITE WIRE-CENTRAL LOCKING
CONTROL
This is only applicable for vehicle that has central locking as
a standard feature. Do not attempt to directly connect the
ORANGE/WHITE wire to any part of the vehicle central
locking system. The ORANGE/WHITE wire is connected to
the optional Sparkrite SR911 Central Locking Interface and
will allow the vehicle’s doors to be locked and unlo cked by
remote control. (An AC1 actuator ma y be required for the
drivers door see page 28 for details).
