13
GREY (L/H): Repeat the above procedure connecting the
GREY wire to the LEFT hand indicator c ircuit.
NOTE: The Alarm gives a 12 volt (+) p o sitive output to flash
the indicators. In the rare case where indicators are
negatively (earth) switched, contact Sparkrite for assistance.
GREEN WIRE-ALARM ANTENNA
The GREEN antenna wire must not be cut or connected to
anything metal otherwise the a larm operating range will be
affected. Extend the GREEN wire and secure to the outside
of the wiring harness to achieve optimum performance.
Ensure the wire cannot come into contact w ith a hot
surface, bare metal or immersed in water
YELLOW WIRE-ELECTRIC FAN INHIBIT
IMPORTANT:If you have a mechanical cooling fan or the
electric fan
does not operate with the ignition
turned off, the n the yellow wire MUST be
connected to a good e arthing point BEFORE
connecting the RED wire of the alarm.
If the electric fan still operates when the ignition is turned
OFF then a connection from the SRA8 must be made to
prevent the current sensing function from triggering the
alarm. The cooling fan wiring will be configured as shown in
Fig. 4 or 5.
NOTE: The engine must be cold before proceeding.
Locate the fan thermal switch by tracing the wirin g from the
fan motor. Connect the YELLOW wire a s sho wn in Fig. 4 or
5 using a solder joint or a crimp termination to the wire
which runs between the fan motor and thermal switch
